Frigidaire FRT18FP5D Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT18FP5D:
- Factory parts catalog (15 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00006.eps N05DAACKA1.eps N05BBAABD3.eps N05SAAAFE10.eps
N05CBBBAC1.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT18KP5DK0 FRT18KP5DQ0 FRT18KP5DS0 FRT18KP5DW0
R134a
R134a
R134a
stainless-LH
bisque
stainless
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
North America North America
North America North America
241858907
241858907
241585907
240379015
240379015
240379015
240568300
240568300
Publication No.
5995412649
04/07/02
(EN/SERVICE/WC)
390
Copyright
R134a
white
115
240398801
240400111
241858907
240379015
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18KP5D /
FRT18FP5D /
FRT18KP5D
©
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18FP5D
Summary of Contents for Frigidaire FRT18FP5D
- Page 1 North America North America North America North America 241858907 241858907 241585907 240379015 240379015 240379015 240568300 240568300 TOP-MOUNT REFRIGERATOR Model No. FRT18KP5D / FRT18FP5D / Publication No. FRT18KP5D 5995412649 04/07/02 (EN/SERVICE/WC) © Copyright 2004 Electrolux Home Products, Inc. R134a white 240398801 240400111 241858907...
- Page 2 Publication No: 5995412649 07/04 FRT18KP5D / FRT18FP5D / FRT18KP5D DOOR N05DAACKA1...
- Page 3 240527102 240527101 215870636 215870633 215870629 218676004 218490901 # Functional Parts * Non-Illustrated Parts FRT18KP5D / FRT18FP5D / FRT18KP5D DOOR A FRT18KP5D (FRT18KP5DK0) B FRT18KP5D (FRT18KP5DQ0) C FRT18KP5D (FRT18KP5DS0) D FRT18KP5D (FRT18KP5DW0) DESCRIPTION A - C - Gasket-frzr door, black, magnetic...
- Page 4 Publication No: 5995412649 07/04 FRT18KP5D / FRT18FP5D / FRT18KP5D CABINET N05BBAABD3...
- Page 5 240354401 5303001609 5308009759 240578901 240335003 218233300 5303292395 # Functional Parts * Non-Illustrated Parts FRT18KP5D / FRT18FP5D / FRT18KP5D CABINET A FRT18KP5D (FRT18KP5DK0) B FRT18KP5D (FRT18KP5DQ0) C FRT18KP5D (FRT18KP5DS0) D FRT18KP5D (FRT18KP5DW0) DESCRIPTION A B C D Cover-fan A B C D...
- Page 6 Publication No: 5995412649 07/04 FRT18KP5D / FRT18FP5D / FRT18KP5D CABINET N05BBAABD3...
- Page 7 5304418225 5303316859 5303001479 240479601 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRT18KP5D / FRT18FP5D / FRT18KP5D CABINET A FRT18KP5D (FRT18KP5DK0) B FRT18KP5D (FRT18KP5DQ0) C FRT18KP5D (FRT18KP5DS0) D FRT18KP5D (FRT18KP5DW0) DESCRIPTION A B C D Screw, hex washer head, 8-18AB x 1.250...
- Page 8 Publication No: 5995412649 07/04 FRT18KP5D / FRT18FP5D / FRT18KP5D SHELVES N05SAAAFE10...
- Page 9 240530601 240530701 240443905 240357802 240350643 5308016566 215005100 # Functional Parts * Non-Illustrated Parts FRT18KP5D / FRT18FP5D / FRT18KP5D SHELVES A FRT18KP5D (FRT18KP5DK0) B FRT18KP5D (FRT18KP5DQ0) C FRT18KP5D (FRT18KP5DS0) D FRT18KP5D (FRT18KP5DW0) DESCRIPTION A B C D Tray, ice cube, plastic...
- Page 10 Publication No: 5995412649 07/04 FRT18KP5D / FRT18FP5D / FRT18KP5D SYSTEM N05CBBBAC1...
- Page 11 5304418225 5303316859 241505701 241544301 240396801 5303918234 5303918263 # Functional Parts * Non-Illustrated Parts FRT18KP5D / FRT18FP5D / FRT18KP5D SYSTEM A FRT18KP5D (FRT18KP5DK0) B FRT18KP5D (FRT18KP5DQ0) C FRT18KP5D (FRT18KP5DS0) D FRT18KP5D (FRT18KP5DW0) DESCRIPTION A B C D Condenser, static A B C D...
-
Page 12: Wiring Schematic
Publication No: 5995412649 FRT18KP5D / FRT18FP5D / FRT18KP5D WIRING SCHEMATIC 07/04... -
Page 13: Wiring Diagram
FRT18KP5D / FRT18FP5D / FRT18KP5D Publication No: 5995412649 WIRING DIAGRAM 07/04 # Functional Parts * Non-Illustrated Parts...
