Frigidaire FRT18FP5D Factory Parts Catalog
Top-mount refrigerator with ice-maker
Hide thumbs
Also See for FRT18FP5D:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00006.eps N05DAACKA1.eps N05BBAAAD0.eps N05SACAFF1.eps
N05CBBBAC1.eps 115-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT18FP5DK0 FRT18FP5DQ0 FRT18FP5DS0 FRT18FP5DW0
R134a
R134a
stainless-lh-dr
bisque
115
115
240398801
240398801
240400111
240400111
North America North America North America North America
241585908
241585908
240379015
240379015
240568300
240398801.eps 240398601.eps
Publication No.
5995412417
04/06/29
(EN/SERVICE/WC)
390
R134a
R134a
stainless
white
115
115
240398801
240398801
240400111
240400111
241585908
241585908
240379015
240379015
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18FP5D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18FP5D
Summary of Contents for Frigidaire FRT18FP5D
- Page 1 North America North America North America North America 241585908 241585908 241585908 240379015 240379015 240379015 240568300 240568300 TOP-MOUNT REFRIGERATOR WITH ICE-MAKER Model No. FRT18FP5D Publication No. 5995412417 04/06/29 (EN/SERVICE/WC) © Copyright 2004 Electrolux Home Products, Inc. R134a white 240398801 240400111 241585908...
- Page 2 Publication No: 5995412417 06/04 FRT18FP5D DOOR N05DAACKA1...
- Page 3 215870633 215870629 218676004 218490901 # Functional Parts * Non-Illustrated Parts FRT18FP5D DOOR A FRT18FP5D (FRT18FP5DK0) B FRT18FP5D (FRT18FP5DQ0) C FRT18FP5D (FRT18FP5DS0) D FRT18FP5D (FRT18FP5DW0) DESCRIPTION A - C - Gasket-frzr door, black, magnetic - B - D Gasket-frzr door, white, magnetic...
- Page 4 Publication No: 5995412417 06/04 FRT18FP5D CABINET N05BBAAAD0...
- Page 5 5303292395 218362500 240516501 5303001343 240442703 # Functional Parts * Non-Illustrated Parts FRT18FP5D CABINET A FRT18FP5D (FRT18FP5DK0) B FRT18FP5D (FRT18FP5DQ0) C FRT18FP5D (FRT18FP5DS0) D FRT18FP5D (FRT18FP5DW0) DESCRIPTION A B C D Cover-fan A B C D Knob-damper control A B C D...
- Page 6 Publication No: 5995412417 06/04 FRT18FP5D CABINET N05BBAAAD0...
- Page 7 241500302 5303001479 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRT18FP5D CABINET A FRT18FP5D (FRT18FP5DK0) B FRT18FP5D (FRT18FP5DQ0) C FRT18FP5D (FRT18FP5DS0) D FRT18FP5D (FRT18FP5DW0) DESCRIPTION - B - D Screw-#10-32 X 3/4, white - B - - Screw-#10-32 X 3/4, bisque...
- Page 8 Publication No: 5995412417 FRT18FP5D SHELVES 06/04...
- Page 9 240443905 240357802 240350643 5308016566 215005100 # Functional Parts * Non-Illustrated Parts FRT18FP5D SHELVES A FRT18FP5D (FRT18FP5DK0) B FRT18FP5D (FRT18FP5DQ0) C FRT18FP5D (FRT18FP5DS0) D FRT18FP5D (FRT18FP5DW0) DESCRIPTION A B C D Shelf-freezer, full width A B C D Diffuser, air, top...
- Page 10 Publication No: 5995412417 06/04 FRT18FP5D SYSTEM N05CBBBAC1...
- Page 11 241544301 240396801 5303918263 5303918234 # Functional Parts * Non-Illustrated Parts FRT18FP5D SYSTEM A FRT18FP5D (FRT18FP5DK0) B FRT18FP5D (FRT18FP5DQ0) C FRT18FP5D (FRT18FP5DS0) D FRT18FP5D (FRT18FP5DW0) DESCRIPTION A B C D Condenser, static A B C D Grommet, rubber, black, cond tube/wire...
-
Page 12: Ice Maker
Publication No: 5995412417 FRT18FP5D ICE MAKER 06/04... - Page 13 5303001549 218888001 240352409 # Functional Parts * Non-Illustrated Parts FRT18FP5D ICE MAKER A FRT18FP5D (FRT18FP5DK0) B FRT18FP5D (FRT18FP5DQ0) C FRT18FP5D (FRT18FP5DS0) D FRT18FP5D (FRT18FP5DW0) DESCRIPTION A B C D Tube-water inlet, inlet valve, to ice maker A B C D...
-
Page 14: Wiring Schematic
Publication No: 5995412417 FRT18FP5D WIRING SCHEMATIC 06/04... -
Page 15: Wiring Diagram
FRT18FP5D Publication No: 5995412417 WIRING DIAGRAM 06/04 # Functional Parts * Non-Illustrated Parts...
