Frigidaire FRT18KC3B Factory Parts Catalog

Frigidaire FRT18KC3B Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18KC3B:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18KC3BW2
FRT18KC3B
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995367777
020308
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KC3B
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18KC3B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT18KC3B

Summary of Contents for Frigidaire FRT18KC3B

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18KC3BW2 FRT18KC3B R134a white MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 TOP MOUNT REFRIGERATOR Model No. ELECTROLUX HOME PRODUCTS, INC FRT18KC3B P.O.
  • Page 2 Publication No. FRT18KC3B2 5995367777 DOOR 03/02...
  • Page 3 FRT18KC3B2 Publication No. 5995367777 DOOR POS. NO PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514606 Gasket-refr door,white ,magnetic 240331401 Rack-door,20.27" x 1.72" 240311502 Support-door rack,2 liter ,RH 240331502 Support-door rack,gallon ,RH 240311501 Support-door rack,2 liter ,LH 240331501 Support-door rack,gallon ,LH 240337703 Door-dairy,w/o graphics ,clear 240331402...
  • Page 4 Publication No. FRT18KC3B2 5995367777 CABINET 03/02...
  • Page 5 FRT18KC3B2 Publication No. 5995367777 CABINET POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462008 Cover-evap coil 240371302 Seal,insulation ,47.77 in. long, foam, coil cover 10*# 240385401 Wiring Harness,freezer section...
  • Page 6 Publication No. FRT18KC3B2 5995367777 SHELVES 03/02...
  • Page 7 FRT18KC3B2 Publication No. 5995367777 SHELVES POS. NO PART NO DESCRIPTION 215667501 Tray-ice,plastic 5303282284 Shelf-freezer,"table type" 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 240392601 Seal-diffuser 240505801 Switch,light/lamp 240436701 Light Bulb/Lamp, A-15, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240352701 Control Box 17*# 240388701 Wiring Harness,control box 240360801 Knob-control 21 #...
  • Page 8 Publication No. FRT18KC3B2 5995367777 SYSTEM 03/02...
  • Page 9 FRT18KC3B2 Publication No. 5995367777 SYSTEM POS. NO PART NO DESCRIPTION 240406404 Condenser,static 240405201 Grommet,rubber ,black ,cond tube/wire 5303208866 Spacer-cond tube,black 5308000296 Bracket,condenser mtg ,(4) 5308000039 Screw,hex washer head, 8-32CA x 0.500, serrated head 5308009617 Washer,ext tooth lock ,#10 ,grounding 218944001 Drier-filter,R134a System 240375401 Wiring Harness, machine compt, w/service cord...

  • Page 10: Wiring Schematic

    Publication No. FRT18KC3B2 5995367777 WIRING SCHEMATIC 03/02...

  • Page 11: Wiring Diagram

    FRT18KC3B2 Publication No. 5995367777 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
