Frigidaire FRT18FS6C Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18FS6C
  6. Factory parts catalog
Frigidaire FRT18FS6C Factory Parts Catalog

Frigidaire FRT18FS6C Factory Parts Catalog

Top mount refrigerator
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18FS6CQ0
FRT18FS6C
FRT18FS6CW0
FRT18FS6C
MARKET
North America
WIRING DIAGRAM - 240379010
OWNER'S GUIDE - 240400109
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995388625
030408
-EN/SERVICE /ECL
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18FS6C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
