Frigidaire FRT17A2A Factory Parts Catalog

Frigidaire FRT17A2A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT17A2A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT17A2AQ3
FRT17A2A
FRT17A2AW3
FRT17A2A
FRT17A2AZ3
FRT17A2A
MARKET
North America
ENERGY GUIDE - 218791450
OWNER'S GUIDE - # 240400110
SERVICE DATA SHEET - # 240379011
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a, Static
bisque
R134a, Static
white
R134a, Static
white
Publication No.
5995398111
031031
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17A2A
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT17A2A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT17A2A

Summary of Contents for Frigidaire FRT17A2A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT17A2AQ3 FRT17A2A R134a, Static bisque FRT17A2AW3 FRT17A2A R134a, Static white FRT17A2AZ3 FRT17A2A R134a, Static white MARKET North America ENERGY GUIDE - 218791450 OWNER’S GUIDE - # 240400110 SERVICE DATA SHEET - # 240379011 TOP MOUNT REFRIGERATOR Model No.
  • Page 2 Publication No. FRT17A2A 5995398111 DOOR 10/03...
  • Page 3 FRT17A2A Publication No. 5995398111 DOOR A = FRT17A2A (FRT17A2AQ3) B = FRT17A2A (FRT17A2AW3) C = FRT17A2A (FRT17A2AZ3) POS. NO PART NO DESCRIPTION 240554101 A B C Gasket-frzr door,white ,magnetic 240542104 A B C Gasket-refr door,white ,magnetic 240535101 A B C Rack-door 240337701 A B C...
  • Page 4 Publication No. FRT17A2A 5995398111 CABINET N05BBAABA11 10/03...
  • Page 5 FRT17A2A Publication No. 5995398111 CABINET A = FRT17A2A (FRT17A2AQ3) B = FRT17A2A (FRT17A2AW3) C = FRT17A2A (FRT17A2AZ3) POS. NO PART NO DESCRIPTION 240355401 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut,push-on 240367401 A B C Damper-fan cover 5308000010 A B C...
  • Page 6 Publication No. FRT17A2A 5995398111 SHELVES 10/03...
  • Page 7 FRT17A2A Publication No. 5995398111 SHELVES A = FRT17A2A (FRT17A2AQ3) B = FRT17A2A (FRT17A2AW3) C = FRT17A2A (FRT17A2AZ3) POS. NO PART NO DESCRIPTION 240545001 A B C Diffuser,air ,top 240362601 A B C Diffuser,air ,bottom 240505801 A B C Switch,light/lamp 240436702 A B C Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701...
  • Page 8 Publication No. FRT17A2A 5995398111 SYSTEM N05CBBBAB0 10/03...
  • Page 9 FRT17A2A Publication No. 5995398111 SYSTEM A = FRT17A2A (FRT17A2AQ3) B = FRT17A2A (FRT17A2AW3) C = FRT17A2A (FRT17A2AZ3) POS. NO PART NO DESCRIPTION 240406405 A B C Condenser,static 240405201 A B C Grommet,rubber ,black ,cond tube/wire 5303208866 A B C Spacer,condenser tube ,black 5308000296 A B C Bracket,condenser mtg ,(4)

  • Page 10: Wiring Schematic

    Publication No. FRT17A2A 5995398111 WIRING SCHEMATIC 10/03...

  • Page 11: Wiring Diagram

    FRT17A2A Publication No. 5995398111 WIRING DIAGRAM # = Fast-moving Parts 10/03 * = Non-Illustrated Parts...
