PRODUCT NO.
BASE MODEL NO.
FRT17GG5AQ0
FRT17GG5AQ
FRT17GG5AW0
FRT17GG5AW
PRODUCT NO.
MARKET
FRT17GG5AQ0
USA
FRT17GG5AW0
USA
WIRING DIAGRAM - #240379007
OWNER'S GUIDE - #240400105
SERVICE DATA SHEET - #240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
ICE MAKER
IM115
IM115
Publication No.
5995359808
011015
-EN/SERVICE /DJH
390
FACTORY
PARTS CATALO
VOLTS
VOLTS
VOLTS
TOP MOUNT
REFRIGERATOR
Model No.
FRT17GG5A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT17GG5A
Summary of Contents for Frigidaire FRT17GG5A
- Page 1 P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a bisque R134a white ICE MAKER IM115 IM115 TOP MOUNT REFRIGERATOR Model No. FRT17GG5A Publication No. 5995359808 011015 -EN/SERVICE /DJH ©2001 White Consolidated Industries, Inc. All rights reserved FACTORY PARTS CATALO VOLTS VOLTS VOLTS...
- Page 2 Publication No. FRT17GG5A 5995359808 DOOR 10/01...
- Page 3 A = FRT17GG5A (FRT17GG5AQ0) B = FRT17GG5A (FRT17GG5AW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT17GG5A DOOR PART NO DESCRIPTION 240514601 Gasket-frzr door,white ,magnetic 240514604 Gasket-refr door,white ,magnetic 240331404 Rack-door,18.65" 240311502 Support-door rack,2 liter ,RH 240311501 Support-door rack,2 liter ,LH...
- Page 4 Publication No. FRT17GG5A 5995359808 CABINET 10/01...
- Page 5 A = FRT17GG5A (FRT17GG5AQ0) B = FRT17GG5A (FRT17GG5AW0) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT17GG5A CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. FRT17GG5A 5995359808 SHELVES 10/01...
- Page 7 A = FRT17GG5A (FRT17GG5AQ0) B = FRT17GG5A (FRT17GG5AW0) POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT17GG5A SHELVES PART NO DESCRIPTION 215667501 Tray-ice,plastic 240358001 Shelf-freezer 5303299664 Spacer-shelf 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 5309918806 Switch-light/lamp...
- Page 8 Publication No. FRT17GG5A 5995359808 SYSTEM 10/01...
- Page 9 A = FRT17GG5A (FRT17GG5AQ0) B = FRT17GG5A (FRT17GG5AW0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT17GG5A SYSTEM...
-
Page 10: Wiring Schematic
Publication No. FRT17GG5A 5995359808 WIRING SCHEMATIC 10/01... -
Page 11: Wiring Diagram
FRT17GG5A Publication No. 5995359808 WIRING DIAGRAM # = Fast-moving Parts 10/01 * = Non-Illustrated Parts...
