Frigidaire FRT17B3A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT17B3A
  6. Factory parts catalog
Frigidaire FRT17B3A Factory Parts Catalog

Frigidaire FRT17B3A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT17B3A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT17B3AQ1
FRT17B3A
FRT17B3AT1
FRT17B3A
FRT17B3AW1
FRT17B3A
FRT17B3AZ1
FRT17B3A
MARKET
North America
WIRING DIAGRAM - #240398801
OWNER'S GUIDE - #240400103
SERVICE DATA SHEET - #240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995354858
010615
-EN/SERVICE /ECL
924
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17B3A
©2001 White Consolidated Industries, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT17B3A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT17B3A

Summary of Contents for Frigidaire FRT17B3A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT17B3AQ1 FRT17B3A R134a bisque FRT17B3AT1 FRT17B3A R134a bisque FRT17B3AW1 FRT17B3A R134a white FRT17B3AZ1 FRT17B3A R134a white MARKET North America WIRING DIAGRAM - #240398801 OWNER’S GUIDE - #240400103 TOP MOUNT SERVICE DATA SHEET - #240379007 REFRIGERATOR Model No.
  • Page 2 Publication No. FRT17B3A 5995354858 DOOR 06/01...
  • Page 3 FRT17B3A Publication No. 5995354858 DOOR A = FRT17B3A (FRT17B3AQ1) B = FRT17B3A (FRT17B3AT1) C = FRT17B3A (FRT17B3AW1) D = FRT17B3A (FRT17B3AZ1) POS. NO PART NO DESCRIPTION 240370903 A B C D Gasket-frzr door,white ,magnetic 240370904 A B C D Gasket-refr door,white ,magnetic 240331404 A B C D Rack-door,18.65"...
  • Page 4 Publication No. FRT17B3A 5995354858 CABINET 06/01...
  • Page 5 FRT17B3A Publication No. 5995354858 CABINET A = FRT17B3A (FRT17B3AQ1) B = FRT17B3A (FRT17B3AT1) C = FRT17B3A (FRT17B3AW1) D = FRT17B3A (FRT17B3AZ1) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
  • Page 6 Publication No. FRT17B3A 5995354858 SHELVES 06/01...
  • Page 7 FRT17B3A Publication No. 5995354858 SHELVES A = FRT17B3A (FRT17B3AQ1) B = FRT17B3A (FRT17B3AT1) C = FRT17B3A (FRT17B3AW1) D = FRT17B3A (FRT17B3AZ1) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray-ice,plastic (Optional Accessory) 5303283280 A B C D Shelf-freezer,"table type" 240362502 A B C D Diffuser-air,top...
  • Page 8 Publication No. FRT17B3A 5995354858 SYSTEM 06/01...
  • Page 9 FRT17B3A Publication No. 5995354858 SYSTEM A = FRT17B3A (FRT17B3AQ1) B = FRT17B3A (FRT17B3AT1) C = FRT17B3A (FRT17B3AW1) D = FRT17B3A (FRT17B3AZ1) POS. NO PART NO DESCRIPTION 240406402 A B C D Condenser,static 5303208866 A B C D Spacer-cond tube,black 5308000296 A B C D Bracket,condenser mtg ,(4) 218944001...

  • Page 10: Wiring Schematic

    Publication No. FRT17B3A 5995354858 WIRING SCHEMATIC 06/01...

  • Page 11: Wiring Diagram

    FRT17B3A Publication No. 5995354858 WIRING DIAGRAM # = Fast-moving Parts 06/01 * = Non-Illustrated Parts...
