Frigidaire FRT17G4B Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT17G4B
  6. Factory parts catalog
Frigidaire FRT17G4B Factory Parts Catalog

Frigidaire FRT17G4B Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT17G4B:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT17G4BQ0
FRT17G4B
FRT17G4BW0
FRT17G4B
MARKET
North America
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995370649
020422
-EN/SERVICE /KC
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17G4B
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FRT17G4B

Summary of Contents for Frigidaire FRT17G4B

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT17G4BQ0 FRT17G4B FRT17G4BW0 FRT17G4B MARKET North America WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - 240379007 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a bisque R134a...
  • Page 2 Publication No. FRT17G4B 5995370649 DOOR 04/02...
  • Page 3 A = FRT17G4B (FRT17G4BQ0) B = FRT17G4B (FRT17G4BW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT17G4B DOOR PART NO DESCRIPTION 240514601 Gasket-frzr door,white ,magnetic 240514604 Gasket-refr door,white ,magnetic 240331404 Rack-door,18.65" 240311502 Support-door rack,2 liter ,RH 240311501 Support-door rack,2 liter ,LH...
  • Page 4 Publication No. FRT17G4B 5995370649 CABINET 04/02...
  • Page 5 A = FRT17G4B (FRT17G4BQ0) B = FRT17G4B (FRT17G4BW0) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT17G4B CABINET PART NO DESCRIPTION 240355401 Cover-fan 240433201 Screw,hex washer head ,8-18 x 0.375 240367001 Knob-damper control 5303001028 Nut,push-on...
  • Page 6 Publication No. FRT17G4B 5995370649 SHELVES 04/02...
  • Page 7 A = FRT17G4B (FRT17G4BQ0) B = FRT17G4B (FRT17G4BW0) POS. NO 14 # 16 # 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT17G4B SHELVES PART NO DESCRIPTION 240358001 Shelf,freezer 5303299664 Spacer,shelf 240362502 Diffuser,air ,top 240362601 Diffuser,air ,bottom...
  • Page 8 Publication No. FRT17G4B 5995370649 SYSTEM 04/02...
  • Page 9 A = FRT17G4B (FRT17G4BQ0) B = FRT17G4B (FRT17G4BW0) POS. NO 14 # 21 # 29 # 30 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT17G4B SYSTEM PART NO DESCRIPTION 240406403 Condenser,static 5303208866 Spacer,condenser tube ,black 240405201...

  • Page 10: Wiring Schematic

    Publication No. FRT17G4B 5995370649 WIRING SCHEMATIC 04/02...

  • Page 11: Wiring Diagram

    FRT17G4B Publication No. 5995370649 WIRING DIAGRAM # = Fast-moving Parts 04/02 * = Non-Illustrated Parts...
