Frigidaire FRT17G4B Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT17G4B
  6. Factory parts catalog
Frigidaire FRT17G4B Factory Parts Catalog

Frigidaire FRT17G4B Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT17G4B:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT17G4BQ1
FRT17G4B
FRT17G4BW1
FRT17G4B
MARKET
North America
WIRING DIAGRAM - 240379010
OWNER'S GUIDE - 240400107
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a, Static
bisque
R134a, Static
white
Publication No.
5995379871
021017
-EN/SERVICE/KHB
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17G4B
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT17G4B and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT17G4B

Summary of Contents for Frigidaire FRT17G4B

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT17G4BQ1 FRT17G4B R134a, Static bisque FRT17G4BW1 FRT17G4B R134a, Static white MARKET North America WIRING DIAGRAM - 240379010 OWNER’S GUIDE - 240400107 TOP MOUNT SERVICE DATA SHEET - 240379010 REFRIGERATOR Model No.
  • Page 2 Publication No. FRT17G4B 5995379871 DOOR 10/02...
  • Page 3 FRT17G4B Publication No. 5995379871 DOOR A = FRT17G4B (FRT17G4BQ1) B = FRT17G4B (FRT17G4BW1) POS. NO PART NO DESCRIPTION 240542101 Gasket,frzr door seal ,white ,magnetic 240542104 Gasket-refr door,white ,magnetic 240535101 Rack-door 240337703 Door-dairy,w/o graphics ,clear 240535001 Rack-door 240381302 Plug-button,bisque ,hinge brg hole ,(2) 240381301 Plug-button,white ,hinge brg hole ,(2) 240420102...
  • Page 4 Publication No. FRT17G4B 5995379871 CABINET 10/02...
  • Page 5 FRT17G4B Publication No. 5995379871 CABINET A = FRT17G4B (FRT17G4BQ1) B = FRT17G4B (FRT17G4BW1) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462004 Cover-evap coil 240532101 Seal,coil cover...
  • Page 6 Publication No. FRT17G4B 5995379871 SHELVES 10/02...
  • Page 7 FRT17G4B Publication No. 5995379871 SHELVES A = FRT17G4B (FRT17G4BQ1) B = FRT17G4B (FRT17G4BW1) POS. NO PART NO DESCRIPTION 240358001 Shelf,freezer 5303299664 Spacer,shelf 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb, A-15, clear, 40 W, 120 V, miniature 16 # 241500701 Socket-light/lamp...
  • Page 8 Publication No. FRT17G4B 5995379871 SYSTEM 10/02...
  • Page 9 FRT17G4B Publication No. 5995379871 SYSTEM A = FRT17G4B (FRT17G4BQ1) B = FRT17G4B (FRT17G4BW1) POS. NO PART NO DESCRIPTION 240406403 Condenser,static 5303208866 Spacer,condenser tube ,black 5308000296 Bracket,condenser mtg ,(4) 218944001 Drier-filter,R134a System 240375401 Wiring Harness, mach compt, w/service cord 6* # 240388701 Wiring Harness,control box 6* #...

  • Page 10: Wiring Schematic

    Publication No. FRT17G4B 5995379871 WIRING SCHEMATIC 10/02...

  • Page 11: Wiring Diagram

    FRT17G4B Publication No. 5995379871 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
