Frigidaire FRT17IB3A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT17IB3A
  6. Factory parts catalog
Frigidaire FRT17IB3A Factory Parts Catalog

Frigidaire FRT17IB3A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT17IB3A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT17IB3AQ2
FRT17IB3A
FRT17IB3AT2
FRT17IB3A
FRT17IB3AW2
FRT17IB3A
FRT17IB3AZ2
FRT17IB3A
MARKET
North America
SERIES
COLOR
R134a, Static
bisque
R134a, Static
bisque
R134a, Static
white
R134a, Static
white
Publication No.
5995370151
020417
-EN/SERVICE/DCS
390
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17IB3A

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT17IB3A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT17IB3A

Summary of Contents for Frigidaire FRT17IB3A

  • Page 1 PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT17IB3AQ2 FRT17IB3A R134a, Static bisque FRT17IB3AT2 FRT17IB3A R134a, Static bisque FRT17IB3AW2 FRT17IB3A R134a, Static white FRT17IB3AZ2 FRT17IB3A R134a, Static white MARKET North America TOP MOUNT REFRIGERATOR Model No. FRT17IB3A Publication No. 5995370151 020417 -EN/SERVICE/DCS...
  • Page 2 DOOR...
  • Page 3 5995370151 DOOR A = FRT17IB3A (FRT17IB3AQ2) B = FRT17IB3A (FRT17IB3AT2) C = FRT17IB3A (FRT17IB3AW2) D = FRT17IB3A (FRT17IB3AZ2) POS. NO PART NO DESCRIPTION 240514601 A B C D Gasket-frzr door,white ,magnetic 240514604 A B C D Gasket-refr door,white ,magnetic 240331404 A B C D Rack-door,18.65"...
  • Page 4 CABINET...
  • Page 5 5995370151 CABINET A = FRT17IB3A (FRT17IB3AQ2) B = FRT17IB3A (FRT17IB3AT2) C = FRT17IB3A (FRT17IB3AW2) D = FRT17IB3A (FRT17IB3AZ2) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401 A B C D...
  • Page 6 SHELVES...
  • Page 7 5995370151 SHELVES A = FRT17IB3A (FRT17IB3AQ2) B = FRT17IB3A (FRT17IB3AT2) C = FRT17IB3A (FRT17IB3AW2) D = FRT17IB3A (FRT17IB3AZ2) POS. NO PART NO DESCRIPTION 5303282284 A B C D Shelf-freezer,"table type" 240362502 A B C D Diffuser,air ,top 240362601 A B C D Diffuser,air ,bottom 240371304 A B C D...
  • Page 8 SYSTEM...
  • Page 9 5995370151 SYSTEM A = FRT17IB3A (FRT17IB3AQ2) B = FRT17IB3A (FRT17IB3AT2) C = FRT17IB3A (FRT17IB3AW2) D = FRT17IB3A (FRT17IB3AZ2) POS. NO PART NO DESCRIPTION 240406403 A B C D Condenser,static 240405201 A B C D Grommet,rubber ,black ,cond tube/wire 5303208866 A B C D Spacer,condenser tube ,black 5308000296 A B C D...

  • Page 10: Ice Maker

    ICE MAKER...
  • Page 11 5995370151 ICE MAKER A = FRT17IB3A (FRT17IB3AQ2) B = FRT17IB3A (FRT17IB3AT2) C = FRT17IB3A (FRT17IB3AW2) D = FRT17IB3A (FRT17IB3AZ2) POS. NO PART NO DESCRIPTION 218976901 A B C D Tube-water inlet, inlet valve to ice maker 5304420650 A B C D Spring,shut-off arm 5308000039 A B C D...

  • Page 12: Wiring Schematic

    WIRING SCHEMATIC...

  • Page 13: Wiring Diagram

    5995370151 WIRING DIAGRAM...
