367
Spezialnähmaschine
Aufstellanleitung
D

Installation Instructions

GB
Instructions de montage
F
Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld
Telefon +49 (0) 5 21/ 9 25-00 • Telefax +49 (0) 5 21/ 9 25 24 35 • www.duerkopp-adler.com
Ausg./Edition: 12/04
Printed in Federal Republic of Germany
Teile-/Part-No.: 0791 367741
