DURKOPP ADLER 911 Operating & Installation Instructions Manual
Cnc-controlled sewing unit with large sewing area
Hide thumbs
Also See for 911:
- Operating & installation instructions manual (42 pages) ,
- Operating & installation instructions manual (70 pages)
Table of Contents
Advertisement
Quick Links
CNC-controlled sewing unit with large
Postfach 17 03 51, D-33703 Bielefeld Ÿ Potsdamer Straße 190, D-33719 Bielefeld
Telefon +49 (0) 5 21/ 59 25-00 Ÿ Telefax +49 (0) 5 21/ 9 25 24 35 Ÿ www.duerkopp-adler.com
Ausgabe / Edition:
Änderungsindex
08/2010
Rev. index: 00.0
Operating Instructions
Installation Instructions
Service Instructions
Printed in Federal Republic of Germany
911
sewing area
Teile-Nr./Part.-No.:
0791 911001
1
2
3
Advertisement
Table of Contents
Related Manuals for DURKOPP ADLER 911
Summary of Contents for DURKOPP ADLER 911
- Page 1 CNC-controlled sewing unit with large sewing area Operating Instructions Installation Instructions Service Instructions Postfach 17 03 51, D-33703 Bielefeld Ÿ Potsdamer Straße 190, D-33719 Bielefeld Telefon +49 (0) 5 21/ 59 25-00 Ÿ Telefax +49 (0) 5 21/ 9 25 24 35 Ÿ www.duerkopp-adler.com Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:...
- Page 2 All rights reserved. Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner, even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited. Dürkopp Adler AG - 2010 Copyright ©...
- Page 3 Foreword This instruction manual is intended to help the user to become familiar with the machine and take advantage of its application possibilities in accordance with the recommendations. The instruction manual contains important information on how to operate the machine securely, properly and economically. Observation of the instructions eliminates danger, reduces costs for repair and down-times, and increases the reliability and life of the machine.
- Page 4 General safety instructions The non-observance of the following safety instructions can cause bodily injuries or damages to the machine. 1. The machine must only be commissioned in full knowledge of the instruction book and operated by persons with appropriate training. 2.
-
Page 5: Table Of Contents
Contents Page: Part 2: Installation Instructions 911 – Original Instructions Scope of delivery ..........General . -
Page 7: Scope Of Delivery
Scope of delivery CNC-controlled sewing unit/pattern stitcher (max. sewing field size 300 x 200 mm) based on the machine head class 867 and a control unit DAC III with a special software. Double-lockstitch machine equipped with: automatic sewing foot and clamp lifting, sewing stroke adjustment. -
Page 8: Installing The Sewing Unit
Installing the sewing unit 3.1 Transport Transport the sewing unit using a lifting cart or a forklift, or its own castors if available. ATTENTION! Before putting the sewing unit into operation, screw out the height adjustable legs 1 until good stability is reached. Lifting the sewing unit –... -
Page 9: Removing The Security Devices
3.2 Removing the security devices Before installing the sewing unit all three securing devices have to be removed. If the sewing unit has to be transported to another place, please remount the securing devices again. -
Page 10: Setting The Working Height
3.3 Setting the working height 3.3.1 Sewing units with rollers The working height can be set between 760 mm and 910 mm (measured up to the upper edge of the table top). Caution: Risk of injury! Do not lift the sewing unit using the table top. Put a lifting cart or a forklift underneath the sewing unit before loosening the clamping screw. -
Page 11: Sewing Units Without Rollers
3.3.2 Sewing units without rollers The working height can be set between 760 mm and 910 mm (measured up to the upper edge of the table top). Caution: Risk of injury! Do not lift the sewing unit using the table top. Put a lifting cart or a forklift underneath the sewing unit before loosening the clamping screw. -
Page 12: Fitting The Foot Pedal
3.4 Fitting the foot pedal The foot pedal can be placed as needed before the sewing unit. -
Page 13: Attaching The Machine Parts Removed For Shipping
Attaching the machine parts removed for shipping 4.1 Thread stand – Insert the thread stand 1 in the drill-hole of the table top and fasten it with nut 2 on top and nut 3 underneath the table top. – Mount and align the thread plate and the unwinding arms as shown in the illustration. -
Page 14: Electrical Connection
Electrical connection ATTENTION! All work on the electrical equipment of this sewing unit may only be carried out by qualified electricians or other appropriately trained persons. The mains plug must be pulled out. 5.1 Connecting to the mains – Plug the mains cable into the socket. 230V -50/60 Hz 5.2 Checking the nominal voltage ATTENTION! -
Page 15: Pneumatic Connection
Pneumatic connection For the operation of pneumatic components, the sewing unit has to be supplied with anhydrous compressed air. ATTENTION! For a trouble-free function of the pneumatic control procedures, the compressed air supply must operate as follows: Even at the moment of the highest air consumption, the minimum operating pressure must not drop below 6 bar. -
Page 16: Oil Lubrication
Oil lubrication Caution: Risk of injury! Oil can cause skin rashes. Avoid longer skin contact. After contact wash yourself thoroughly. ATTENTION! The handling and disposal of mineral oils is subject to legal regulations. Deliver used oil to an authorized collecting station. Protect your environment. -
Page 17: Putting Into Operation
Putting into operation A sewing test should be carried out when setting-up is complete. – Plug the mains cable into the socket. Caution: Risk of injury! Turn off the main switch. The needle and hook threads may only be threaded with the sewing unit switched off. - Page 18 Notes:...
