Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld
Telefon +49 (0) 521 / 9 25-00 • Telefax +49 (0) 521 / 9 25 24 35 • www.duerkopp-adler.com
Ausgabe / Edition:
Änderungsindex
05/2008
Rev. index: 01.0
Spezialnähmaschine
Printed in Federal Republic of Germany
171 Ÿ 173
Betriebsanleitung

Instruction manual

Teile-Nr./Part.-No.:
0791 171621
D
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 171 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Duerkopp Adler 171

Summary of Contents for Duerkopp Adler 171

  • Page 1: Instruction Manual

    171 Ÿ 173 Spezialnähmaschine Betriebsanleitung Instruction manual Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld Telefon +49 (0) 521 / 9 25-00 • Telefax +49 (0) 521 / 9 25 24 35 • www.duerkopp-adler.com Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.: 05/2008...
  • Page 2 Alle Rechte vorbehalten. Eigentum der Dürkopp Adler AG und urheberrechtlich geschützt. Jede, auch auszugsweise Wiederverwendung dieser Inhalte ist ohne vorheriges schriftliches Einverständnis der Dürkopp Adler AG verboten. All rights reserved. Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner, even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.
  • Page 3 Foreword This instruction manual is intended to help the user to become familiar with the machine and take advantage of its application possibilities in accordance with the recommendations. The instruction manual contains important information on how to operate the machine securely, properly and economically. Observation of the instructions eliminates danger, reduces costs for repair and down-times, and increases the reliability and life of the machine.

  • Page 4: General Safety Instructions

    General safety instructions The non-observance of the following safety instructions can cause bodily injuries or damages to the machine. 1. The machine must only be commissioned in full knowledge of the instruction book and operated by persons with appropriate training. 2.

  • Page 5: Table Of Contents

    Index Page: — Part 2: Installation instructions class 171 Scope of delivery ..........General notes and securing devices .

  • Page 7: Scope Of Delivery

    Scope of delivery The scope of delivery is dependent on your order. Prior to setting up, please check that all required parts are present. This description is valid for a special sewing machine the individual components of which are completely delivered by Dürkopp Adler AG. Equipment (according to subclass): –...

  • Page 8: Assembling The Stand

    Assembling the stand 3.1 Assembling the stand components – Mount the individual parts of the stand as shown in the illustration. – Push the attached four stand feet 6 on. – Slightly loosen the screws 4 on both sides of the cross struts 7 to ensure the stability of the stand.

  • Page 9: Completing The Table Top With The Control And Fastening It To The Stand

    3.2 Completing the table top with the control and fastening it to the stand – Insert the machine head support 15 into the bore of the table top (class 171 only). – Insert the rubber supports 14 for the machine head into the recesses of the table top 12.

  • Page 10: Setting The Working Height

    3.4 Setting the working height – The working height can be adjusted between 750 and 900 mm (measured up to the top edge of the table top). – Loosen screws 1 at the spars of the stand. – Position the table top horizontally at the desired working height. In order to avoid jamming pull out or push in both sides of the table top equally.

  • Page 11: Sewing Drives

    Sewing drives 4.1 Drive category, type and use The following sewing drives are available: Subclass Clutch motor Clutch positioning drive positioning drive 0171-131110 FIR 1147-F.752.3 9889 017101 1 FIR 1148.552.3 0171-141621 Efka DC1500/DA220C 0173-141110 FIR 1147-F.752.3 9889 017101 1 FIR 1148.552.3 0173-141621 Efka DC1500/DA220C 4.2 Numbers of stitches for three-phase current drives depending on the average...

  • Page 12: Mounting The Sewing Drive

    4.3 Mounting the sewing drive – Fasten the sewing drive 2 with its base 1 to the underside of the table top. For this purpose screw the 3 hexagonal bolts (M8 x 15) with washers in the screwed inserts 8 of the table top. 4.4 Mounting the pedal –...

  • Page 13: Mounting The Control For Machines With Direct Drive

    4.5 Mounting the control for machines with direct drive – Mount control 1 with 4 screws under the table top 8. – Fasten the power supply cable of the control with the strain relief clamp under the table top. 4.6 Mounting the set value initiator –...

  • Page 14: Mounting The Machine Head

    Mounting the machine head 5.1 Fitting the machine head ATTENTION! Remove the supporting screws at the front and in the center before tilting the machine head into the working position. – Insert machine head 1 in tilted position into the cutout of the table top.

  • Page 15: Earthing

    5.2 Earthing (direct drive) The earthing wire on the sewing machine head bleeds off static charges of the machine head via the motor control unit to the mass. – Fasten the earthing wire 3 to the provided connection at the control.

  • Page 16: Fitting And Tensioning The V-Belt

    5.3 Fitting and tensioning the V-belt...
  • Page 17 Dismounting the protective devices – Remove the handwheel 2. – Remove the cover of the belt protection at the sewing drive. Fitting the V-belt on and mounting the protective devices – Guide the V-belt 3 through the belt protection 1 and place it on the belt pulley 6 of the machine head .

  • Page 18: Connecting The Sewing Drive

    Connecting the sewing drive 6.1 Connecting the sewing drive to the mains ATTENTION ! Work of every kind on the electric equipment of the special sewing machine must only be carried out by electricians or correspondingly trained personnel. The mains plug has to be pulled out! The manufacturer’s operating instructions enclosed to the sewing drive have to be observed in any case! 6.1.1...

  • Page 19: Setting The Machine-Specific Parameters

    – Plug the cable of the reference value transmitter (pedal) into bushing B80 of the control. – Plug the cable of the motor sensor 1 into bushing B2 of the control. – Plug the cable 2 of the motor into bushing B41 of the control. –...

  • Page 20: Adjusting The Sewing Drive

    Adjusting the sewing drive 7.1 Rotation sense of the sewing drive Attention! Before putting the special sewing machine into operation check the rotation sense of the sewing drive by all means! Operating the special sewing machine with a wrong rotation sense may cause damage.

  • Page 21: Pneumatic Connection

    8. Pneumatic connection ATTENTION ! The faultless function of the pneumatic aggregates is only guaranteed if the net pressure amounts to 8 to 10 bar. The operating pressure of the sewing machine amounts to 6 bar. Pneumatic connection package Under the order number 0797 003031 a pneumatic connection package for stands with compressed air maintenance unit is available.

  • Page 22: Lubrication

    Lubrication Caution: Risk of injury ! Oil may cause skin eruption. Avoid a longer contact with the skin. Wash yourself thoroughly after a contact. ATTENTION ! The handling and disposal of mineral oils is subject to legal regulation. Deliver used oil to an authorised collection point. Protect your environment.

  • Page 23: Oil Return

    9.1 Oil return The oil return gathers the oil running into the oil pan and feeds it into the oil circulation via a pump. Wrap the suction filter 3 of the oil return with the felt and fasten it to the oil sheet with clamp 2.
  • Page 24 Table top cutout (FIR drive)
  • Page 25 Table top cutout (direct drive)
  • Page 26 For your own notes:...
