Amplifier.
A fuse is located just under the mains input (location 3 in figure 1). Replacement is
simple and a spare fuse is provided inside the fuse housing itself. Always use the
correctly rated fuse, as indicated on the silk screen printing, there are two different types
according to the operating voltage.
Qualified and authorised personnel should undertake any other servicing regarding the
electronic section.
In case of any malfunction of the unit, the first thing to be checked should be the input
connection, more especially if the source has unbalanced outputs (see "Operating
Instructions" section) as improper connection can result in significant level reduction and
affect the response.

List of spare parts.

PART NUMBER
9900 0362
7900 0413
7900 0414
7900 0406
4504 5725
6184 0043
6481 0290
6730 0355
6460 0083
7300 0622
7900 0504
7900 0505
For any query regarding any other individual electronic spare parts, please contact
your local distributor.

Warranty

No maintenance of the System 800A is necessary.
All components are guaranteed for a period of one year from the date of
manufacture, subject to the absence of, or evidence of, misuse, overload or
accidental damage.
For further information please contact your dealer or the distributor in your country.
If you cannot locate your distributor please contact :
Customer Services Department
Tannoy Limited
Coatbridge
ML5 4TF
Scotland
Telephone
Fax
E-mail
DO NOT SHIP ANY PRODUCT TO TANNOY WITHOUT PREVIOUS
AUTHORISATION.
This warranty in no way affects your statutory rights.
DESCRIPTION
System 800A Cabinet assembly
Driver kit
Recone kit for LF unit
HF diaphragm assembly
Screw M5 x 30mm hex countersunk black
Port tube
System 800A User manual
Carton kit System 800A
Moulded badge & label
System 800A amplifier- complete unit
System 800A amplifier- cross-over/amplifier PCB (fitted)
System 800A amplifier- plate fitted with transformer / switches
01236 420199 (UK)
01236 428230 (UK)
prosales@tannoy.com
+44 1236 420199 (International)
+44 1236 428230 (International)
