TECHNICAL SPECIFICATIONS

System
Frequency response ( 3 dB)
Maximum SPL (peak @ 1 m)
Maximum SPL at mix position
Distortion
Dispersion (@ -6dB)

Electronic section

Input
connector
Sensitivity
Crossover frequency
Amplifier output power
Output noise
(HF channel, 20Hz - 20 kHz unweighted)
User controls and indicators
Supply
Cabinet
Drive unit
Low frequency design
Cabinet construction
Cabinet finish
Cabinet dimensions (HxWxD)
Cabinet weight
Shipping dimensions (HxWxD)
Shipping weight
Tannoy operate a policy of continuous research and development. The introduction of new materials or manufacturing
methods will always equal or exceed the published specifications which Tannoy reserve the right to alter without prior
notice. Please verify the latest specifications when dealing with critical applications.
(one pair driven)
LF channel (6 Ohms load)
HF channel (6 Ohms load)
Input level, LF contour, HF contour (switches)
Power ON/OFF switch, Power ON LED, mains voltage selector.
Self-contained PSU with detachable mains power cord
Mains voltage adjustable to 220-240V or 110-120V
Fuse T1.25A/250V (220-240V range) or T2.5A/250V (110-120V range)
Power consumption 10 to 280 VA
8 "Tannoy Dual Concentric type 2046
Bass-reflex load using flared port tubes, in 21 litres
MDF (36 mm) front and back panels,
19 mm high density particle board.
Two panels fitted with magnetic shielding plates.
Tannoy Dark Blue – Front Baffle
Hide grey - Sides
275 mm x 450 mm x 290 mm
13 kg
390 mm x 545 mm x 360 mm
17 kg
44 Hz - 20 kHz
110 dB SPL
120 dB SPL
< 0.5%
90 conical
10 k balanced on combined XLR/jack
Adjustable, +4 dBu or -10 dBu
1600 Hz
90 W rms
90 W rms
-80 dBV
