Pro-Ject 6

Controls, features and connections

1 Sub-chassis transport screw
2 Drive pulley
3 Drive belt *
4 Operation indicator
5 Sandwich platter *
6 Tonearm counterweight * 6a Downforce scale
7 Tonearm lift lever
8/18 Tonearm rest and removable transport lock
9 Tonearm tube
10 Lid *
11 Lid hinges
12 Hinge fasteners
13 Power supply socket
14 Phono output sockets and earth connection
15 Anti-skating weight adjustment scale
16 Anti-skating weight *
17 Anti-skating weight wire support
20 Power switch
21 Headshell with finger lift
22 Adjustable tip-toe feet with anti-scratch cups *
23 Motor unit with Sorbothane
24 Sub-chassis
A, B, C Knurled sub-chassis levelling screws
Screw-down record clamp (not shown) *
Connection cable (not shown) *
Power supply (not shown) *
Single adapter *
Spirit level (not shown) *
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO record player.
In order to achieve maximum performance and reliability with this record player you should study these instructions
for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable
receptacle.
Before starting assembly make yourself acquainted with the parts listed above and correspondingly numbered
in the technical drawings above. Separately packed items are marked with an asterisk *.
PerspeX
3a Hook *
9a Tonearm base
® pad *
© Audio Trade GmbH · Pro-Ject 6 PerspeX · Revision 2012.7.1
3
