DIGITAL BLOOD PRESSURE MONITOR
IDENTIFICATION OF PARTS
Cuff
Hose plug
Rubber cuff hose
TM
INSTRUCTION MANUAL
FOR
REF CH-403C
Battery cover
Memory reset switch
- Eng 1 -
Systolic blood pressure
display section
Hose socket
Power switch
Start switch
Memory recall switch
Pressure setting switch
Diastolic blood pressure/
Pulse display section
Advertisement
Table of Contents
Related Manuals for Citizen CH-403C
Summary of Contents for Citizen CH-403C
-
Page 1: Identification Of Parts
INSTRUCTION MANUAL DIGITAL BLOOD PRESSURE MONITOR REF CH-403C IDENTIFICATION OF PARTS Systolic blood pressure display section Cuff Battery cover Hose socket Diastolic blood pressure/ Memory reset switch Pulse display section Power switch Start switch Hose plug Memory recall switch Rubber cuff hose Pressure setting switch - Eng 1 -... -
Page 2: Specifications
SPECIFICATIONS Measuring method: Oscillometric system Indication: Digital display, Height: 19mm Measuring range: Pressure; 0 280mmHg, Pulse; 40 200 beat/min. Accuracy: Pressure; 3mmHg, Pulse; 5% Inflation: Automatic inflation by internal pump Pressurization setting: 4 stage: 130, 160, 200, 250mmHg Deflation: Automatic constant speed deflation system Exhaust: Quick exhaust by electromagnetic valve Memory function:... -
Page 3: General Remarks
CLEANING METHOD OF CUFF After cleaning the cuff with a neutral detergent, lightly rinse it in a washing machine will cause air leakage. Also, be careful with water and let it dry in the air. Hard rubbing or washing not to get water into the air hose. GENERAL REMARKS General Remarks on blood pressure For proper measurement of blood pressure... -
Page 4: Precaution For Use And Maintenance
• Measure blood pressure with a relaxed and quiet posture. • Do NOT keep on measuring so many times, as your arm Keep the center of the cuff at the level of your heart, and do will have built up congestion of blood, and you will not get NOT move your arm or talk during measurement. - Page 5 Protect the nature environment: Manufacturer: Please help protect natural environment by respecting na- Name: Premier Precision Ltd. tional and/or local recycling regulations when disposing of Address: Block E, G-H, 6 floor, the batteries and the products at the end of their useful lives. Phase 2, Yip Fat Factory Building, 73-75 Hoi Yuen Road, Kwun Tong, Kowloon, Hong Kong...
- Page 6 SYSTOLIC mmHg DIASTOLIC mmHg SYSTOLIC mmHg DIASTOLIC mmHg PULSE/min PULSE/min AVE. AVE. All display marks appear for approx. 1 second and buzzer beeps. SYSTOLIC mmHg DIASTOLIC mmHg SYSTOLIC mmHg DIASTOLIC mmHg PULSE/min AVE. Ready for measurement PULSE/min AVE. 2. Attaching of arm cuff and posture during measurement After all display marks are disappeared, deflation mark “...
- Page 7 Wind the arm cuff around the left upper arm tightly so that the bottom edge of the cuff is positioned about 1-2 cm (about The cuff should be wound so that one finger can be in- 1 inch) above the elbow joint. serted under the cuff.
- Page 8 3. Select the value for pressure for mea- 4. To start the measurement surement Press the “Start Switch”. Press the “Pressure Setting Switch” and set the value to a The arm cuff pressurizes when the “Start Switch” is pressed. value approximately 20~30mmHg above your normal systolic blood pressure.
-
Page 9: Turn Power Off
5. Turn power off SYSTOLIC mmHg DIASTOLIC mmHg Press the “Power Switch” to turn OFF. 6. Subsequent measurements PULSE/min AVE. When a pulse is detected, the pressure value moves to the right side of the display. At this time the mark “Q” flashes and buzzer sounds. -
Page 10: Memory Recall
8. Memory recall SYSTOLIC mmHg DIASTOLIC mmHg PULSE/min AVE. • By a second depressing of “Memory Recall Switch”, the value for latest (last measured value) blood pressure is dis- played. The “ ] ” mark shifts to right (from “Ave.” to “1”) and notify that the value is the last measured (newest one) value. -
Page 11: Battery Replacement
— Memory function works on for approximately 3 seconds 10. Battery replacement or until another switches are pressed. (Even if the last mea- If the batteries become weak, the “ ” mark will appear in sured value is displayed, you are able to start the mea- the display, indicating that batteries should be replaced with surements by pressing of “Start Switch”... -
Page 12: Description Of Display Marks
DESCRIPTION OF DISPLAY MARKS DISPLAY MARK CONDITION/CAUSE CORRECTIVE ACTION SYSTOLIC mmHg DIASTOLIC mmHg Measurement is begun, but the pressure Change the pressurization setting one level by pressing was insufficient. “Pressure Setting Switch” and measure once again. (Automatic re-measuring will be done only 1 time.) PULSE/min AVE. - Page 13 CITIZEN is a registered trademark of Citizen Watch Co., Japan. Consumer Electronics Division CBM Bldg. 5F, 5-68-10, Nakano, Nakano-ku, Tokyo 164-0001, Japan Phone: (03)5345-7430 Fax: (03)5345-7431 E-mail: info-con@jcbm.co.jp...
