Using Projection Features
Specifying a Contour
Use the following procedure for contour specification of the currently projected image.
1.
Select [Specify Contour] on the [Image] menu or click
toolbar.
2.
On the contour specification dialog box, use your mouse to drag the
handles on the selection boundary to change its size and shape until
the boundary encloses the area you want to extract.
Clicking with the mouse near a corner handle causes the handle to jump to the point
where you clicked.
Use the corner handles to change the size and orientation of the selection boundary.
Drag the selection boundary lines to change the size of the selection boundary, without
changing its orientation.
3.
When the selection boundary is the way you want, click [OK].
This extracts the area enclosed in the boundary of the selection boundary and adjusts
the extracted area so it is rectangular.
91
on the
Selection boundary
Drag the handles to
reshape.
