Page 2
BUNN’S SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND. In no event shall Bunn be liable for any other damage or loss, including, but not limited to, lost profits, lost sales, loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute equipment, facilities or services, or any other special, incidental, consequential or punitive damages.
CLEANING The use of a damp cloth rinsed in any mild, non-abrasive, liquid detergent is recommended for cleaning all surfaces on Bunn-O-Matic equipment. Check and clean the sprayhead. The sprayhead holes must always remain open. With the sprayhead removed, insert the deliming spring (provided) all the way into the sprayhead tube.
TROUBLESHOOTING A troubleshooting guide is provided to suggest probable causes and remedies for the most likely problems encountered. If the problem remains after exhausting the troubleshooting steps, contact the Bunn-O-Matic Technical Service Department. • Inspection, testing, and repair of electrical equipment should be performed only by qualified service person- nel.
Page 6
3. Sprayhead A six-hole stainless steel spray- head must be used for proper extraction. 4. Funnel Loading The BUNN paper filter must be ® centered in the funnel and the bed of grounds leveled by gentle shaking.
Page 7
TROUBLESHOOTING (cont.) PROBLEM PROBABLE CAUSE REMEDY Dry coffee grounds remain in the 1. Funnel Loading The BUNN paper filter must be ® funnel centered in the funnel and the bed of grounds leveled by gently shaking. Brewer is making unusal noises 1.
SERVICE The tank inlet fitting secures the fill basin to the tank lid This section provides procedures for testing and replacing various major components used in this brewer should service become necessary. Refer to Troubleshooting for assistance in determining the cause of any problem.
Page 9
SERVICE (cont.) Removal and Replacement: Remove wires from control thermostat leads or terminals. Location: Remove the thermostat capillary bulb by firmly The control thermostat is located inside the hood pulling-up on the capillary at the tank lid. This on the left end of the mounting bracket. will disengage the grommet from the tank lid.
SERVICE (cont.) Removal and Replacement: Remove all wires from limit thermostat termi- LIMIT THERMOSTAT nals. Carefully slide the limit thermostat out from under the retaining clip and remove limit thermostat. Carefully slide the new limit thermostat into the retaining clip. Refer to Fig.
Page 11
SERVICE (cont.) If continuity is present as described, reconnect the wires, the tank heater is operating properly. If continuity is not present as described, replace the tank heater. NOTE- If the tank heater remains unable to heat, remove and inspect heater for cracks in the sheath. Removal and Replacement: Remove the tank inlet fitting securing the fill basin to the tank lid, remove fill basin and tank...
