I N S T R U C T I O N B O O K
FOR ELECTROLUX
COOKER HOOD
CH 710
UK
cod. 436002549_01 - 050128

Advertisement

loading

  Related Manuals for Electrolux CH 710

  Summary of Contents for Electrolux CH 710

  • Page 1 I N S T R U C T I O N B O O K FOR ELECTROLUX COOKER HOOD CH 710 cod. 436002549_01 - 050128...
  • Page 3: For The Installer

    If you require guidance in the use of the appliance or require further in- formation on Electrolux Products, please contact our Customer Care Department. For general enquiries concerning your Electrolux appliance or for further information, visit our website at http://www.electrolux.co.uk...
  • Page 4: Important Safety Information

    • Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or more serious malfunction. Refer to your local Electrolux Service Force Centre. Always insist on genuine spare parts.
  • Page 5: Your Appliance

    OPERATING INSTRUCTIONS This cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. Cooker Hood Controls The cooker hood functions are controlled by four push button switches located centrally in the control fascia. Turns the worktop lighting On and Off Mains light - illumination indicates fan motor is running V1 Turns the fan motor On and Off at low speed,...
  • Page 6 To Operate Select the required fan speed and light if required. Recirculation In the recirculation mode the contaminated air enters the cooker hood through the grease fi lters. The air is cleaned by passing through the charcoal fi lters before being passed back into the kitchen through the grilles in either side of the chimney stack.
  • Page 7: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fi re hazard. External Cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent.
  • Page 8 Position the new charcoal fi lter in the position marked and while holding the fi lter replace the fi xing hooks as illustrated. This appliance can be a possible fi re hazard if the grease and charcoal fi lters are not cleaned and replaced as recommended.
  • Page 9: Something Not Working

    For general assistance with your appliance or for further information on Electrolux products please contact our Customer Care Department. Customer Care Department, Electrolux 55 - 77 High Street...
  • Page 10: Guarantee Conditions

    GUARANTEE CONDITIONS We Electrolux, undertake that if within twenty four months of the date of the purchase this Electrolux built-in applian- ce or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that: •...
  • Page 11: Installation Instructions

    INSTALLATION INSTRUCTIONS It is dangerous to alter the specifi cations or attempt to modify this product in any way. Technical Information DIMENSIONS ELECTRICAL SUPPLY: Note: CE Marking certifi es that this appliance complies with the requirements laid down in EEC directive 89:336. (Electromagnetic compatibility) and subsequent modifi...
  • Page 12: Installing The Cooker Hood

    INSTALLING THE COOKER HOOD Please ensure that when the appliance is installed it is easily accessible to an engineer in the event of a breakdown. All installations must comply with the local authorities requirements for the discharge of exhaust air. Incorrect installation may affect the safety of this cooker hood.
  • Page 13 INSTALLING THE COOKER HOOD Clearance Height The cooker hood is designed to be fi tted over a cooking appliance at the clearance heights stated, providing the maximum output of the appliance beneath does not exceed the maximums quoted in the Technical Speci- fi...
  • Page 14: Fitting The Wall Brackets

    INSTALLING THE COOKER HOOD Fitting the Wall Brackets Wall marking: • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of the area in which the hood will be installed. •...
  • Page 15 INSTALLING THE COOKER HOOD Fitting the Hood Body Before starting to fi x the hood body, tighten the two screws Vr located on the top of the hood body. Hook the hood body onto the two 4.2x44.4mm screws item 12a. Fully tighten the screws item 12a.
  • Page 16 INSTALLING THE COOKER HOOD Extraction The charcoal fi lter is not required in this mode and should be removed. Ducting The ducting used must be Ø150mm (6ins), or Ø125mm (5ins) in diameter. If possible duct through the wall immediately above the hood body. For the best performance use the shortest possible duct run and the minimum number of bends.
  • Page 17: Fitting The Chimney Stack

    INSTALLING THE COOKER HOOD Fitting the Chimney Stack The chimney consists of two sections. The lower chimney measures 740mm and the upper chimney (with the recirculation grilles on either side) measures 465mm. The overall installed measurement is min. 870 - max 1200mm.
  • Page 20 55 - 77 High Street - Slough BERKSHIRE SL1 1DZ © Electrolux plc 2002...
