Maintenance and Lubrication Schedule

Remove pump module cover and inspect:
• Hydraulic hoses, fittings and connections for wear
1500
or leaks
Cycles
• Harness cables, wires, terminals and connections
for securement or damage
• Control board, circuit breaker, power switch and
lights for securement or damage
Perform all procedures listed in previous section also
Inspect cotter pins on platform pivot pin (2)
Hydraulic Fluid (Pump) - Check level. Note: Fluid
should be changed if there is visible contamination.
Inspect the hydraulic system (cylinder, hoses, fit-
tings, seals, etc.) for leaks if fluid level is low.
Inspect cylinders, fittings and hydraulic connections
for wear, damage or leaks
Inspect outer barrier cylinder hose assembly (hose,
fasteners, connections, etc.) for wear, damage or
leakage
Inspect parallel arms, bushings and pivot pins for
visible wear or damage
4500
Inspect parallel arm pivot pin mounting bolts (8)
Cycles
Inspect platform pivot pin, bushings and vertical
arms for wear, damage and positive securement
Inspect upper/lower fold arms, rotating pivot slide
arms, slide support arms and associated pivot pins,
bushings, and bearings for visible wear or damage
Inspect gas springs (cylinders) for wear or damage,
proper operation and positive securement (IB)
Inspect rotating pivot slide arm UHMW slide bear-
ings (buttons - 2) and UHMW slide (1)
Inspect vertical arm plastic covers
Inspect power cable
Mounting
Decals and Antiskid
Repeat all previously listed inspection, lubrica-
Consecutive
tion and maintenance procedures at 750 cycle
750 Cycle
intervals.
Intervals
Resecure, replace or correct as needed.
Resecure, replace or correct as needed
Use Braun 32840-QT (Exxon ®
hydraulic fluid (do not mix with Dextron III or other
hydraulic fluids). Check fluid level with platform
lowered fully and roll stop unfolded fully. Fill
to within 1/2" of the bottom of the 1-1/2" fill tube
(neck).
Tighten, repair or replace if needed.
Tighten, repair or replace if needed.
Replace if needed.
Tighten or replace if needed.
Replace defective parts and resecure as needed.
Apply Light Grease during reassembly procedures.
Replace if needed.
Tighten, replace or correct as needed
Apply Door-Ease or replace if needed. See Lubri-
cation Diagram.
Resecure or replace if needed.
Resecure, repair or replace if needed.
Check to see that the lift is securely anchored to
the vehicle and there are no loose bolts, broken
welds, or stress fractures.
Replace decals if worn, missing or illegible. Re-
place antiskid if worn or missing.
Univis HVI 26)
Page 15
