Braun NL501 Series Service Manual

Braun NL501 Series Service Manual

Public use wheelchair lifts
Hide thumbs Also See for NL501 Series:
Table of Contents

Advertisement

Quick Links

"Providing Access to the World"
International Corporate Hdqrs: P.O. Box 310
®
1-800-THE LIFT
(574) 946-6153
37221 Rev. A
April
2012
Service Manual for:
NL501
Public Use Wheelchair Lifts
Series
DOT — Public Use Lift
DOT — Public Use Lift
"DOT — Public Use Lift" verifies that this platform lift meets the
"public use lift" requirements of FMVSS No. 403. This lift may be
installed on all vehicles appropriate for the size and weight of the
lift, but must be installed on buses, school buses, and multi-
purpose passenger vehicles other than motor homes with a gross
vehicle weight rating (GVWR) that exceeds 4,536 kg (10,000 lb).
®
®
Winamac, IN 46996 USA
FAX: (574) 946-4670
01
01
W ARNING
Read manual
before installing
or servicing lift.
Failure to do so
may result in
serious bodily
injury and/or
property damage.
