Chapter 1
Feature Cisco 1841 Series
Wireless LAN Software
Features
Wireless LAN Security IEEE 802.1X per-user, per-session mutual authentication with
a variety of extensible authentication protocol (EAP) types
Features
including Cisco LEAP, Protected Extensible Authentication
Protocol (PEAP), and EAP-Transport Layer Security
(EAP-TLS). Preshared Key (PSK) Authentication; MAC
authentication/filter encryption; WPA Temporal Key Integrity
Protocol (TKIP) with support for per-packet key hashing,
message integrity check; Static and dynamic wired
equivalent privacy (WEP) keys of 40 bits and 128 bits;
Additional security features: IEEE 802.1X local
authentication; Configurable limit for the number of wireless
clients; Configurable RADIUS accounting for wireless clients
SSIDs 8
Wireless LAN Supported by CiscoWorks 2000, CiscoView and Router, and
Security Device Management (SDM)
Management Features GUI-based network management for wireless interface is
provided
Cisco IOS Software default IP BASE -12.4(1)
Cisco IOS Software default IP Base (security and broadband bundles have image
upgrades)
User Support Up to 50 users (recommended)
Routing Protocols BGP, EIGRP, OSPF, RIPv1, RIPv2
Routed Protocols IPv4, IPv6 unicast and multicast (Internetwork Packet
Exchange [IPX], IBM SNA, AppleTalk supported with optional
Advanced Enterprise Services Feature Set)
QoS Protocols Weighted Fair Queuing (WFQ), Class-Based WFQ (CBWFQ),
Weighted Random Early Detection (WRED), Committed
Access Rate (CAR), Resource Reservation Protocol (RSVP),
Network-Based Application Recognition
Internal system power Yes
supply
Power over Ethernet (PoE) None
power supply
Redundant power supply No
DC power support No
AC input voltage 100 to 240 VAC
Frequency 50 to 60 Hz
AC input current 1.5A maximum
Output power 50W (maximum)
PoE Support Not supported
PoE Standards None
External PoE Power Supply None
System Power Dissipation 153 BTU/hr.
Operating temp 32 to 104×F (0 to 40×C)
Operating humidity 10 to 85% non condensing operating; 5 to 95% non
condensing, non operating
Non operating Temp -4 to 149ºF (-25 to 65ºC)
Operating altitude 10,000 feet (3000 meters) @ 77ºF (25ºC)
Noise level Normal operating temperature: <78º F/25.6ºC: 34 dBA;
>78ºF/25.6ºC through; 104ºF/40ºC
Safety UL60950-1; CAN/CSA 60950-1; AS 3260; EN60950-1
EMI EN 55022, 1998, class A; CISPR22, 1997, class A; CFR47, Part
15, Subpart B, 1995, class A; EN61000-3-2 Harmonic Current
Emission (only for equipment >75W but <16A); EN61000-3-3
Voltage Fluctuation and Flicker (only for equipment £16A)
Cisco 1800 Series
Fixed-Configuration Routers
Maximize throughput or maximize range option;
Software-configurable transmit power; Support
for Wi-Fi Multimedia (WMM); Quality of Service
(QoS) for WLANs
IEEE 802.1X per-user, per-session mutual
authentication with a variety of extensible
authentication protocol (EAP) types including
Cisco LEAP, Protected Extensible Authentication
Protocol (PEAP), and EAP-Transport Layer
Security (EAP-TLS). Preshared Key (PSK)
Authentication; MAC authentication/filter
encryption; WPA Temporal Key Integrity Protocol
(TKIP) with support for per-packet key hashing,
message integrity check; Static and dynamic
wired equivalent privacy (WEP) keys of 40 bits
and 128 bits; Additional security features: IEEE
802.1X local authentication; Configurable limit for
the number of wireless clients; Configurable
RADIUS accounting for wireless clients
8
Supported by CiscoWorks 2000, CiscoView and
Router, and Security Device Management (SDM)
GUI-based network management for wireless
interface is provided
12.3(8)YI
Advanced IP services (without voice services)
except Cisco 1801 and 1802 which also come
with Cisco IOS IP Broadband
Up to 50 users (recommended)
BGP, EIGRP, OSPF, RIPv1, RIPv2
IPv4, IPv6 unicast and multicast (Internetwork
Packet Exchange [IPX], IBM SNA, AppleTalk
supported with optional Advanced Enterprise
Services Feature Set)
Weighted Fair Queuing (WFQ), Class-Based WFQ
(CBWFQ), Weighted Random Early Detection
(WRED), Committed Access Rate (CAR),
Resource Reservation Protocol (RSVP),
Network-Based Application Recognition
Yes
None
No
No
100 to 240 VAC
50 to 60 Hz
1.5A maximum
50W (maximum)
Supported on 10/100 Ethernet switch ports with
optional PoE kit
IEEE 802.3af, Cisco Prestandard PoE
80W external power supply
153 BTU/hr.
32º to 104ºF (0º to 40ºC)
10 to 85 percent non condensing operating; 5 to
95 percent non condensing, non operating
-4º to 149ºF (-25 to 65ºC)
10,000 ft. (3000m) at 77ºF (25ºC)
<80ºF (27ºC): 34 dBA; >80ºF (27ºC) through <104ºF
(40ºC): 36 dBA; >104ºF (40ºC): 42 dBA
UL 60950; CAN/CSA C22.2 No. 60950; IEC 60950-1;
EN 60950-1; AS/NZS 60950
CFR 47 Part 15, Class A; ICES-003 Class A;
EN55022 Class A; CISPR22 Class A; AS/NZS 3548;
lass A; VCCI Class A; EN 300386; EN61000-3-2;
EN61000-3-3
1-9
