10 C 1: I
HAPTER NTRODUCING THE

Router 5682 Hardware

System Specifications
R 5000 F
OUTER AMILY
Table 9 System Specifications for the Router 5642 (continued)
Item
Fixed ports
Boot ROM
SDRAM
Flash
Dimensions
(W x H x D)
Weight
Input voltage
Max. power
Operating temperature
Operating humidity
The Router 5682 has two fixed ports and eight slots.
Figure 7 illustrates the front panel of the Router 5682.
Figure 7 Front Panel of the Router 5682
Figure 8 illustrates the back panel of the Router 5682 with MIM cards installed.
Figure 8 Back Panel of the Router 5682
Table 10 lists system specifications for the Router R5682.
Table 10 System Specifications for the Router 5682
Item
Fixed ports
Slots
Processor
NVRAM
Boot ROM
Router 5642 specifications
1 AUX port
1 CONSOLE port
512 KB
256 MB
32 MB
442 x 44.4 x 413 mm (17.5 x 1.8 x 16.25 in)
excluding rubber feet
8 kg (17.64 lbs)
Rated voltage: 100-240 V a.c.; 50/60 Hz
Maximum tolerance: 90-264 V a.c.; 50/60 Hz
80 W
0 to 40 O C
5 to 85% (non-condensing)
Router 5682 specifications
1 AUX port
1 console port
8 (MIM)
MPC 8245 300 MHz (AC power supply and
DC power supply)
128 KB
512 KB
