Bogen RPK84 Installation Manual

Model: RPK84
PCM2000
Rack Mounting Kit

Installation

1. Position the left side of the completed PCM assembly over one of the rack mounting
adapters. Refer to the figure above and the table below to determine the correct
holes for the number of modules in the assembly.
Total Modules
Mounting Holes
2. Secure the left side of the PCM system to the rack adapter using two of the truss
head sheet metal screws included with the kit.
3. Secure the right side of the PCM system to the other rack adapter using the holes
for the number of modules in the assembly and the remaining two truss head sheet
metal screws.
4. Secure the assembly to a 19" rack (rack screws not supplied).
Specifications subject to change without notice.
© 2000 Bogen Communications, Inc.
Part No. 54-2032-01R3 Printed in Korea. 0203
C
B
A

RACK MOUNTING

SCREWS ARE NOT
SUPPLIED
2 3
C & D B & D
F
E
D
RACK MOUNTING
Rack Mounting A Typical
A 4 MODULE ASSEMBLY

4-Module Assembly

4 5
B & E B & F
50 Spring Street, Ramsey, New Jersey 07446
Tel. 201-934-8500, Fax: 201-934-9832
www.bogen.com
6
A & F
