Bogen RPK87 Installation Manual

Model: RPK87
Power Vector Amplifier
Rack Mounting Kit
Specifications subject to change without notice.
© 2009 Bogen Communications, Inc.
Part No. 54-2073-01B 0907
Power Vector amplifiers may be mounted in 19" racks using the
RPK87 rack mounting kit. After having attached the rack ears, place
the amplifier into the rack and secure it to the rack with appropriate
hardware (not included).

To Attach the Rack Ears:

1. If any feet have been attached to the bottom of the amplifier,
remove them before proceeding.
2. Remove and discard the five cover screws from each side of
the amplifier chassis, as shown above (same both sides).
3. Position the rack ears as shown in the drawing above.
4. Replace the cover screws with the five screws included and
tighten to secure the rack ears. Only use included screws to
mount rack ears.

Installation
