Verifying connectivity

Hide thumbs Also See for OneVision DEFINITY G3 Fault Management:

Table of Contents

The MIB

You can verify that the Proxy Agent is connected to the switch by viewing the

status of the g3connectState field in your MIB.

To access this field, select the procedure for one of the following network

management systems:

HP OpenView

GIS StarSENTRY

HP OpenView

To access the g3connectState field using HP OpenView, follow these steps:

1. Starting on your configuration map, select the DEFINITY icon for the

switch that you want to check.

2. Select Monitor from the menu bar, then select DEFINITY.

3. Select PBX MIB Values from the DEFINITY pull-down menu.

4. Select Connect Group...

If the value in the Switch Connect State field is up, the switch you

selected is connected to the Proxy Agent.

GIS StarSENTRY

To access the g3connectState field using GIS StarSENTRY, follow these steps:

1. Starting on your configuration map, double-click on the DEFINITY icon for

the switch that you want to check.

Result: The Main View window displays:

2. Select Objects from the menu bar.

3. Select G3-ATT from the Objects pull-down menu.

4. Select Connect Data...

If the value in the State field is up, the switch you selected is connected

to the Proxy Agent.

Issue 1 June 1995
