Summary of Contents for Electrolux EOD980
- Page 1 Model EOD980...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. EOD 980 Voltage: Wattage: Height: Width: Depth: Weight: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. 230-240 Volts AC 50Hz 5.0/-5.4kW 897mm 592mm 563mm (excluding handles and knobs) 53kg... -
Page 3: Table Of Contents
Warnings ... 7 Things to Note ... 7 Getting Things Ready ... 7 Choice of Electrical Connection ... 7 Preparing Cabinet for Fitting Oven ... 7 Recommended Cabinet Dimensions ... 8 How to Finish Unpacking ... 9 Tools Required ... 9 Making the Electrical Connections ... - Page 4 Care and Cleaning ... 23 Cleaning Materials ... 23 Cleaning the Outside of the Appliance ... 23 Cleaning Inside the Oven / Grill Compartment ... 23 Cleaning the Grill and Oven Furniture ... 23 Cleaning Between the Outer and Inner Door Glass ... 23 Replacing the Oven Light Bulb ...
-
Page 5: Safety
Never place plastic or any other material which may melt in the oven. Ensure cooking utensils are large enough to contain foods to prevent spillages and boil overs. -
Page 6: After Use
17. Never line any part of the appliance with foil. Do not allow heatproof cooking material, e.g. roasting bags, to come into contact with oven elements. Always stand appliance when opening the oven door to allow any build up of steam or heat to release. -
Page 7: Installation Instructions
By connecting to a cooker point (having a double Safety may be b) By connecting the appliance together with a hob c) If you wish to connect an oven and a hob to a NOTE: It is good practice to : ·... -
Page 8: Recommended Cabinet Dimensions
RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES) Cross section through cabinet showing oven positioned FIG. 2 BUILT IN INSTALLATION... -
Page 9: How To Finish Unpacking
· Ensure the owner is given these operating instructions. TOOLS REQUIRED The following tools will be needed and it helps to assemble them before starting to install your oven: A terminal screwdriver (3mm wide blade) A pozidrive screwdriver Pliers Wirestrippers... -
Page 10: Connecting To The Mains Terminal
· Lift cover and remove screw from cable clamp. See Fig. 5. Fig.5 CONNECTING TO MAINS TERMINAL Warning: This appliance must be earthed. · Make connection as shown in Fig. 6 by proceeding as follows:- Fig.6 · Preform wires to the appropriate shape to suit fitting into the mains terminal block. -
Page 11: Fitting Into The Cabinet
FITTING INTO THE CABINET IMPORTANT: Ensure that the oven is switched off at the wall before any further work is carried out. · Using a tape measure establish the internal width of the cabinet. Refer to page 7 if greater than 565mm. -
Page 12: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED GETTING TO KNOW YOUR OVEN Please note: EOD980gr screening will differ from that shown in the diagram. - Fan Oven Temperature Control - Fan Oven Indicator Neon - Grill Control - Oven Timer... -
Page 13: Rating Plate
Do not remove the rating plate from the appliance as this may invalidate the guarantee. GENERAL NOTES ON USING THE OVEN We suggest that you run the oven elements for 10 – 15 minutes at 220 C to burn off any residue from their surfaces. -
Page 14: Grill And Oven Furniture
GRILL AND OVEN FURNITURE The following items of grill and oven furniture have been supplied with the appliance. If you require replacements of any of the items listed below please contact your local Service Force Service, quoting the relevant part number. -
Page 15: The Grill
THE GRILL USES OF THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL Please note: EOD980gr screening will differ from that show in the diagram. · To operate the grill open the grill door and turn the grill control in either direction. -
Page 16: Hints And Tips
Liver Lamb/Pig Sausages Steaks – Rare Toasted sandwiches Shelf positions are counted from the bottom of the oven upwards. The times quoted above are given as a guide and should be adjusted to suit personal taste. FOOD SHELF Pork... -
Page 17: The Fan Oven
5 – 10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g. bread, pastries, scones, soufflés etc., best results are achieved if the oven is preheated first. For best results when cooking frozen or cooked chilled ready meals always preheat the oven first. -
Page 18: Hints And Tips
A slight increase in cooking time may be necessary. · DO NOT place baking trays directly on the oven floor as it interferes with the oven air circulation and can lead to base burning; use the lower shelf position. -
Page 19: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges... -
Page 20: Roasting Chart
ROASTING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C; Medium : 60-70°C; Well done : 70-80°C... -
Page 21: Defrosting
· Turn the main oven temperature control to the defrost setting. · The oven fan and internal oven light will come · The cooling fan does not operate. THINGS TO NOTE Care must always be taken when handling foods in the home. -
Page 22: Helpful Hints When Buying And Preparing Food
7. It is preferable to defrost frozen foods slowly in the refrigerator. Alternatively, a microwave oven or the Defrost function on your oven may be used. 8. Always cook defrosted foods immediately after thawing. Thawed food should never be refrozen. -
Page 23: Care And Cleaning
All removable parts, except the grill pan handle can be washed in the dishwasher. The grill pan, grill pan grid and oven shelves may be cleaned using a soap impregnated steel wool pad. Soaking first in hot soapy water will make cleaning easier. -
Page 24: To Clean The Inner Glass Door Panels
TO REMOVE THE OUTER GLASS 1. Open the oven door slightly to gain access to the two cross head screws on the top of the oven door. 2. Loosen the two screws using a Pozidrive screwdriver. 3. Hold the door glass securely in place with one hand before removing the screws completely with the other hand. -
Page 25: Replacing The Oven Light Bulb
Fit the new bulb by turning in a clockwise direction until it is secure. Ensuring the indent to the flange is pointing to the rear of the oven, replace the glass by pushing it firmly into the hole to cover the bulb assembly. -
Page 26: Something Not Working
The grill works but the main oven does not: * Check that the grill control is in the OFF position. * Switch OFF at the wall to allow the oven to cool. Check that the oven is now working normally. -
Page 27: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Electrolux appliance, or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below:- Customer Care Department Electrolux 55 –... -
Page 28: Guarantee Conditions
STANDARD GUARANTEE CONDITIONS We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... -
Page 29: Notes
NOTES... - Page 30 NOTES...
- Page 31 NOTES...
- Page 32 This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. ELECTROLUX 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ. TELEPHONE 0870 5 950950 Part Number: 311581006 © Electrolux plc 2002...
