Summary of Contents for Avenview VGA-C5A-R
Page 1
No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.
Removal, installation, and set-up service charges. Safety Instructions The Avenview VGA-C5A-R, VGA & Audio Receiver over Single CAT5 has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment’s, the VGA-C5A-R should be used with care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
Introduction With only one cost effective CAT-5e cable, the Avenview VGA-C5A-R lets you extend VGA (WUXGA) to cover the distance up to 300m (1,000ft). With built-in EQ and GAIN control, the transmission path can be adjusted to adapt the cable quality and video bandwidth. Furthermore, the VGA RGB delay control [de-skew] function provides the compensation among R, G, B signals due to long transmission or through normal LAN cable.
Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire. Do not twist or pull by force ends of the optical cable. It can cause malfunction. www.avenview.com...
4. GAIN: Rotary control for Gain Control of G, B respectively R, G, B respectively 5. Rotary Control: R=0~2, G=3~5, B=6~7 6. Push button to decrease level of for de-skew compensation on respective de-skew compensation color channel 7. Push button to increase level of de-skew compensation www.avenview.com...
Installation To setup Avenview VGA-C5A-R follow these steps for connecting to a device: 1. Connect VGA display to VGA-C5A-R 2. Connect CAT5/CAT6 cable between Transmitter (VGA-C5A-S or VGA-C5SP-4 or VGA-C5SP-8) and Receiver (VGA-C5A-R) 3. Ensure that cables are tightly connected 4.
Dimensions (L x W x H) 4.8” x 3.7” x 1” Power Supply 5V 2A DC Power Consumption 5 Watt (max) Environmental Operating Temperature 32˚ ~ 104˚F (0˚ to 40˚C) Storage Temperature -4˚ ~ 140˚F (-20˚ ~ 60˚C) Relative Humidity 20~90% RH (no condensation) www.avenview.com...
Page 10
4. Because the quality of the LAN cables has the major effects in how long transmission distance will be made and how good is the received display, the actual transmission length is subject to your LAN cables. For resolution greater than 1080i or 1280x1024, a CAT-6 cable is recommended.. www.avenview.com...
Page 11
Disclaimer While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of...
