</PHONE_CONFIG>
8. Verification Steps
The following steps may be used to verify the configuration:
Verify that SpectraLink 8400 Series successfully registers with SIP Enablement Services
server by following the Users Registered Users link on the SES Administration Web
Interface.
Place calls to and from SpectraLink 8400 Series and verify that the calls are successfully
established with two-way talk path.
While calls are established, Enter status trunk <t:r> command, where t is the SIP trunk
group configured in Section 5.6, and r is trunk group member. This will verify whether
the call is shuffled or not.
9. Conclusion
SpectraLink 8400 Series was compliance tested with Communication Manager (Version 5.2.1)
and SIP Enablement Services (Version 5.2.1). SpectraLink 8400 Series (UCS 4.0.0.10555)
functioned properly for feature and serviceability. During compliance testing, SpectraLink 8400
Series successfully registered with SIP Enablement Services, placed and received calls to and
from SIP and non-SIP telephones, and executed other telephony features like three-way
conference, transfers, hold, etc.
10. Additional References
The following Avaya product documentation can be found at
[1] Administering Avaya Aura™ Communication Manager, Release 5.2, Issue 5.0, May 2009,
Document Number 03-300509.
[2] Administering Avaya Aura™ SIP Enablement Services on the Avaya S8300 Server, Issue 2.0,
May 2009, Document Number 03-602508.
The following document was provided by Polycom SpectraLink.
[3] Polycom® SpectraLink® 8400 Series Wireless Handset User Guide, February 2011, 1725-
36720-001 Rev A
CRK; Reviewed:
SPOC 7/1/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
http://support.avaya.com
Polycom8400-SES
20 of 21
