Atlantis Land Web Share 111U User Manual

Dual-port adsl2+ modem/router
Hide thumbs Also See for Web Share 111U:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Web Share 111U and is the answer not in the manual?

Questions and answers

Related Manuals for Atlantis Land Web Share 111U

Summary of Contents for Atlantis Land Web Share 111U

  • Page 2: Table Of Contents

    INDEX 1. Introduction ....................... 7 1.1 An Overview of WebShare 111U ..............7 1.2 Package Contents ..................8 1.3 Technical Features ..................9 1.4 WebShare 111U Application ................ 11 2. Using WebShare 111U ..................11 2.1 Cautions for using the WebShare 111U ............11 2.2 The Front LEDs ..................
  • Page 3 6.4 LAN TCP/IP……………………………………………………………………………………………40 6.5 Configuring LAN ..................42 7. WAN Setup ....................... 44 7.1 WAN Overview ..................44 7.2 PPPoE Encapsulation .................. 44 7.3 PPTP Encapsulation ..................44 7.4 Traffic Shaping ..................45 7.5 Configuring WAN Setup ................46 8. Network Address Translation (NAT) ..............49 8.1 NAT Overview....................
  • Page 4 11.4 SysRestart ....................84 11.5 Diagnostic 85 12. Status ......................86 12.1 Device Info ....................86 12.2 System Log ..................... 87 12.3 Statistics 88 APPENDIX A: Troubleshooting ................90 APPENDICE B: Technical Specifications ..............96 APPENDICE C: Support ..................97 A02-RA111U(v1.5)_ME01 (v1.0 Mar 2009)
  • Page 5 Windows™ 98SE/2000/ME/XP/VISTA are trademarks of Microsoft® Corp. Pentium is trademark of Intel. All copyright reserved. The Atlantis Land logo is a registered trademark of Atlantis Land. All other names mentioned mat be trademarks or registered trademarks of their respective owners.
  • Page 6 Declaration of Conformity Hereby, Sidin SpA, declares that this product (A02-RA111U) is in compliance to all relevant essential requirements of R&TTE Directive (99/5/CE). CE Declaration is available on the web site www.atlantis-land.com. Important information for the correct recycle/treatment procedures of this equipment The mentioned information are reported herewith in compliance with directive 2002/95/CE, 2002/96/CE and 2003/108/CE which requires a separate collection system and specific treatment and disposal procedures for the waste of electric and...

  • Page 7: Introduction

    1. Introduction 1.1 An Overview of WebShare 111U Welcome to the WebShare 111U. Your WebShare 111U is an “all-in-one” unit, combining an ADSL2+ modem, ADSL router and Ethernet network switch, providing everything you need to get the machines on your network connected to the Internet over your ADSL broadband connection.

  • Page 8: Package Contents

    For advanced users, Virtual Service function allows the product to provide limited visibility to local machines with specific services for outside users. An ISP (Internet Service Providers) provided IP address can be set to the product and then specific services can be rerouted to specific computers on the local network. For instance, a dedicated web server can be connected to the Internet via the product and then incoming requests for HTML that are received by the product can be rerouted to the dedicated local web server, even though the server now has a different IP address.

  • Page 9: Technical Features

    1.3 Technical Features Technical charateristics of WebShare 111U: ADSL Multi-Mode Standard: • supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It also supports rate management that allows ADSL subscribers to select an Internet access speed suiting their needs and budgets.
  • Page 10 for one access account. No PPPoE client software is required for local computer. The Automatic Reconnect and Disconnect Timeout (Idle Timer) functions are provided, too. Dynamic Host Control Protocol (DHCP) client and server: • In the WAN site, the DHCP client can get an IP address from the Internet Service Provider (ISP) automatically.

  • Page 11: Webshare 111U Application

    1.4 WebShare 111U Application Follow the followings steps to cabling the device: • Connect WAN Port to the telephone line throught RJ-11 cable (contained in package). • WebShare 111U can be connect in the following configuration: Directly to the PC, throught CAT5 cables (one is contained in package) or USB cable (also provided with the device).

  • Page 12: The Front Leds

    2.2 The Front LEDs MEANING Lit red when power is ON. Lit green when the system is ready. • Lit when connected to an Ethernet device. • Lit green for both 10M and 100M. • Blinking when data is Transmitted / Received. Lit when the device is connected to the PC and is working properly.

  • Page 13: The Rear Ports

    2.3 The Rear Ports PORT MEANING Connect the supplied RJ-11 (“telephone”) cable to this LINE (RJ11) port when connecting to the ADSL/telephone network. User can connect to PC using an alternative USB cable through this port. Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to the Ethernet port when connecting to a PC or an office/home LAN (RJ45) network of 10Mbps or 100Mbps.

  • Page 14: Cabling

    2.4 Cabling First you must connect the product to the ADSL line through the RJ11 cable you have in equipment (in the port LINE) and connect the AC Adapter to the WebShare 111U and then to the socket. Once you’ve checked all the connections and you’ve switched on the Router the product will carry on immediately a diagnosis (about 10 seconds).

  • Page 15: Ethernet Connection

    2.5 Ethernet Connection WebShare 111U is equipped with a 10/100 Mbps Ethernet port (with RJ-45 connector) to permits the connection between a PC (with Fast Ethernet NIC and TCP/IP stack installed) and the Modem/Router. For operationg systems older than Windows 2000, you might install TCP/IP stack separately in order to use WebShare 111U.

  • Page 16: Usb Connection

    2.6 USB Connection Do not plug USB Modem to Your PC before install USB driver. WebShare 111U also has provided with an USB port in order to connect the device with a PC using a free USB port (rev1.1 or 2.0). 2.7 USB Driver To use WebShare 111U with USB connection, You have to install driver provided into Cd-Rom.
  • Page 17 Select the installation mode between Typical (suggested), Compact and Custom. Choosing Custom installation’s method, you have to confirm destination path for driver installation and which components You have to install. Now, the installation utility will ask You to plug USB modem to your PC.

  • Page 18: Installing Webshare 111U

    When You plug USB modem to your PC, the operating system can start an automatic procedure to install new devices; please stop this in order to complete the installation. Follow instrunctions shown on the screen in order to complete the installation.

  • Page 19: Tcp/Ip Configuration

    • Username: admin • Password: atlantis • LAN IP Address: 192.168.1.254 • Subnet Mask: 255.255.255.0 • ISP setting in WAN side: PPPoA, VCMux, Routing, VPI=8, VCI=35 • Firewall=Enabled , SPI=Disabled • DHCP Server enabled with IP pool from 192.168.1.100 to 192.168.1.199 If you ever forget the password to log in, you may press the RESET button up to 6 seconds to restore the factory default settings.
  • Page 20 Please follow the steps below for your PC’s network environment installation. First of all, please check your PC’s network components. The TCP/IP protocol stack and Ethernet network adapter must be installed. If not, please refer to your Windows- related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the WebShare 111U.

  • Page 21: Verification Of Tcp/Ip Configuration

    Configuring PC (Windows Vista) Go to Start -> Control Panel (in Classic View). In the Control Panel, double-click on Network and Sharing Center icon. Click Manage Network connections then double-click Local Area Connection. Click Properties. Click Continue (Windows needs your permission to continue). Select Internet Protocol Version 4 (TCP/IP) and click Properties.

  • Page 22: Browser Configuration

    It i s possibile to continue to follow step. If it show you follow message: Pinging 192.168.1.254 with 32 bytes of data: Request timed out. Request timed out. Request timed out. Check that LAN LED is lit (change CAT cable if is not). Check PC IP Address typing winipcfg for (Win95,98,ME) or ipconfig (for Win2000,XP) and eventually re-install TCP/IP stack.
  • Page 23 Click on WebShare Configuration Assistant icon to select the utility. Step 1: Welcome...
  • Page 24 Step 2: Hardware Installation The Hardware Installation screen will appear. Four links are shown on the screen. Click them one by one and follow the guidelines to complete hardware installation.
  • Page 25 Step 3: Network Card Selection Please select ADSL Company ADSL USB Modem interface to use WebShare thorugh USB port. If this interface will not show into the interface list, please remove and re-install USB driver.
  • Page 26 Step 4: Diagnostic 1 If connection fails, the screen will show FAIL, please check your router if it is connected correctly.
  • Page 27 Step 5: Configuration Details Set up more detailed settings such as VPI, VCI and MTU. Please enter Username and Password as supplied by your ISP (Internet Service Provider).
  • Page 28 Step 6: Diagnostic 2...
  • Page 29 Step 7: Setup Completed Congratulations!! You’ve completed the setup procedure and are ready to surf the Internet. The IE browser will open up automatically when you finish installing.

  • Page 30: Browser Configuration

    4.2 Browser Configuration Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click Go. The default username and password are admin and atlantis. Now, You have access to the Site Map Configuration Interface, subdivided as following: •...
  • Page 31 Click on the desired item to expand the page with all settings in the main navigation panel. Click on the desired item to expand the page with all settings in the main navigation panel.

  • Page 32: Configuring Password

    4.3 Configuring Password It is highly recommended that you change the password for accessing the ADSL Router. To change the ADSL Router’ password, click Maintenance and then Administration . The screen appears as shown: The following table describes the labels in this screen: Label Description New Password...

  • Page 33: Quick Start

    Press the RESET button for 10 (or more) seconds, and then release it. When the PWR LED begins red, the defaults have been restored and the ADSL Router restarts. 5. Quick Start This chapter provides information on the Wizard Setup screens in the web configurator.
  • Page 34 • RFC 1483 (Bridged and Routed Mode): RFC 1483 describes two methods for Multiprotocol Encapsulation over ATM Adaptation Layer 5 (AAL5). The first method allows multiplexing of multiple protocols over a single ATM virtual circuit (LLC-based multiplexing) and the second method assumes that each protocol is carried over a separate ATM virtual circuit (VC-based multiplexing).
  • Page 35 The following screen will appear: You can change the password as you like and then click Next to continue; select your time zone from the drop down list. Please click Next to continue. Select how the router will set up the Internet connection: •...
  • Page 36 In case of PPPoE choose Connection Type=PPPoE LLC and click on Next. You have to pay particular attention to the WAN-ADSL connection. If you have any doubt turn to qualified personnel or contact Atlantis- Land technical assistance. Atlantis Land will not be considered responsible in case of wrong or bad configuration.
  • Page 37 Static IP Address This configuration is valid in case of a subscription with a static IP and active NAT SUA (for the managing of the public class turn to the CD Manual). Make sure that the parameters are, in case of RFC1483, the ones in the picture, if not specifically shown by the ISP.

  • Page 38: Lan Setup

    The Webshare 111U automatically tests the connection to the computer(s) connected to the LAN ports. To test the connection from the ADSL Router to the ISP, click Maintenance then Diagnose. 6. LAN Setup This chapter describes how to configure LAN settings. 6.1 LAN Overview A Local Area Network (LAN) is a shared communication system to which many computers are attached.

  • Page 39: Dns Server Address Assignment

    know the IP address of a machine before you can access it. The DNS server addresses that you enter in the DHCP setup are passed to the client machines along with the assigned IP address and subnet mask. There are two ways that an ISP disseminates the DNS server addresses. The first is for an ISP to tell a customer the DNS server addresses, usually in the form of an information sheet, when s/he signs up.

  • Page 40: Lan Tcp/Ip

    Leave the DNS Server fields in DHCP Setup blank (for example 0.0.0.0). The ADSL Router acts as a DNS proxy when this field is blank. 6.4 LAN TCP/IP The ADSL Router has built-in DHCP server capability that assigns IP addresses and DNS servers to systems that support DHCP client capability.
  • Page 41 None - the ADSL Router will not send any RIP packets and will ignore any RIP packets received. The Dynamic Route field controls the format and the broadcasting method of the RIP packets that the ADSL Router sends (it recognizes both formats when receiving). RIP- 1 is universally supported;...

  • Page 42: Configuring Lan

    6.5 Configuring LAN Click Interface Setup, then LAN to open the following screen: The following table describes the labels in this screen: Router Local IP Field Description IP Address Enter the IP address of the ADSL Router in dotted decimal notation, for example, 192.168.1.254 (factory default).
  • Page 43 RIP Direction Select the RIP direction from None, Both, In Only and Out Only. Dynamic Route Select the RIP version from RIP-1, RIP-2B and RIP-2M. Multicast IGMP (Internet Group Multicast Protocol) is a session-layer protocol used to establish membership in a multicast group. The ADSL Router supports both IGMP version 1 (IGMP-v1) and IGMP- v2.

  • Page 44: Wan Setup

    7. WAN Setup This chapter describes how to configure WAN settings. 7.1 WAN Overview A WAN (Wide Area Network) is an outside connection to another network or the Internet. See the Wizard Setup chapter for more information on the fields in the WAN screens. 7.2 PPPoE Encapsulation The ADSL Router supports PPPoE (Point-to-Point Protocol over Ethernet).

  • Page 45: Traffic Shaping

    7.4 Traffic Shaping Traffic Shaping is an agreement between the carrier and the subscriber to regulate the average rate and “burstiness” or fluctuation of data transmission over an ATM network. This agreement helps eliminate congestion, which is important for transmission of real time data such as audio and video connections. Peak Cell Rate (PCR) is the maximum rate at which the sender can send cells.

  • Page 46: Configuring Wan Setup

    7.5 Configuring WAN Setup To change the ADSL Router’s WAN remote node settings, click Interface Setup then Internet. The screen differs by the encapsulation.
  • Page 47 The following table describes the labels in this screen: Field Description ATM VC Virtual Circuit VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) define a virtual circuit. Status Activated or Deactivated The valid range for the VPI is 0 to 255. Enter the VPI assigned to you.
  • Page 48 Service Name (PPPoE only) Type the name of your PPPoE service here. Enter the user name exactly as your ISP assigned. If assigned a User Name name in the form user@domain where domain identifies a service name, then enter both components exactly as given. A static IP address is a fixed IP that your ISP gives you.

  • Page 49: Network Address Translation (Nat)

    Address Translation) function for this VC. The NAT function can be activated or deactivated per PVC basis. if enable this function, the current PVC will be the default gateway Default Route to internet from this device. RIP (Routing Information protocol) Select this option to specify the RIP version, including RIP-1, RIP-2M and RIP-2B.

  • Page 50: Nat Definitions

    8.1.1 NAT Definitions Inside/outside denotes where a host is located relative to the ADSL Router, for example, the computers of your subscribers are the inside hosts, while the web servers on the Internet are the outside hosts. Global/local denotes the IP address of a host in a packet as the packet traverses a router, for example, the local address refers to the IP address of a host when the packet is in the local network, while the global address refers to the IP address of the host when the same packet is traveling in the WAN side.

  • Page 51: Nat Application

    preventing intruders from probing your network. For more information on IP address translation, refer to RFC 1631, The IP Network Address Translator (NAT). 8.1.3 How NAT Works Each packet has two addresses – a source address and a destination address. For outgoing packets, the ILA (Inside Local Address) is the source address on the LAN, and the IGA (Inside Global Address) is the source address on the WAN.

  • Page 52: Nat Mapping Types

    8.1.5 NAT Mapping Types NAT supports five types of IP/port mapping. They are: • One to One: In One-to-One mode, the ADSL Router maps one local IP address to one global IP address. • Many to One: In Many-to-One mode, the ADSL Router maps multiple local IP addresses to one global IP address.

  • Page 53: Sua (Single User Account) Versus Nat

    The following table summarizes these types: Type IP Mapping One-to-One ILA1 IGA1 Many-to-One (SUA/PAT) ILA1 IGA1 ILA2 IGA1 … Many-to-Many Overload ILA1 IGA1 ILA2 IGA2 ILA3 IGA1 ILA4 IGA2 … Many-to-Many No Overload ILA1 IGA1 ILA2 IGA2 ILA3 IGA3 … Server Server 1 IP IGA1 Server 2 IP IGA1...
  • Page 54 example both FTP and web service), it might be better to specify a range of port numbers. You can allocate a server IP address that corresponds to a port or a range of ports. Many residential broadband ISP accounts do not allow you to run any server processes (such as a Web or FTP server) from your location.
  • Page 55 PC AnyWhere 5632 UDP, 22 UDP, 5631 5632 UDP, 22 UDP, 5631 TCP, 65301 TCP TCP, 65301 TCP Edonkey/Emule Nessuno principalmente 4660-4662 TCP , 4665-4672 UDP MSN Messanger Nessuno TCP da 6891-6900 TCP 1863 TCP 6901 UDP 1863 UDP 6901 UDP 5190 Nessuno TCP 5900...
  • Page 56 rlogin 513/tcp rexec 514/tcp talk 517/tcp and 517/udp ntalk 518/tcp and 518/udp Open Windows 2000/tcp and 2000/udp Network File System (NFS) 2049/tcp 6000/tcp and 6000/udp Routing Information Protocol (RIP) 520/udp Layer 2 Tunnelling Protocol (L2TP) 1701/udp 8.3.2 Virtual Server Click on Advanced Setup then NAT. Click on Virtual Server.
  • Page 57 The following table describes the labels in this screen: Field Description Start Port No. Enter a port number in this field. To forward only one port, enter the port number again in the End...
  • Page 58 Port No. field. To forward a series of ports, enter the start port number here and the end port number in the End Port No. field. End Port No. Enter a port number in this field. To forward only one port, enter the port number again in the Start Port No.

  • Page 59: Selecting The Nat Mode

    8.4 Selecting the NAT Mode Click Advanced Setup then NAT to open the following screen chose Multiple (Numbers of IP). Click on IP Address Mapping (for Multiple IPs Service).
  • Page 60 Ordering your rules is important because the ADSL Router applies the rules in the order that you specify. When a rule matches the current packet, the ADSL Router takes the corresponding action and the remaining rules are ignored. If there are any empty rules before your new configured rule, your configured rule will be pushed up by that number of empty rules.
  • Page 61 The following table describes the labels in this screen: Field Descriptions Rule Index Choose the number Rule Type • 1-1: One-to-one mode maps one local IP address to one global IP address. Note that port numbers do not change for the One-to-one NAT mapping type. •...

  • Page 62: Access Management

    9. Access Management 9.1 Access Control List (ACL) Access Control Listing allows you to determine which services/protocols can access which WEBSHARE 111U interface from which computers. You can configure the router for remote Telnet access or upload and download router firmware and configuration files using FTP.
  • Page 63 Application Choose a service that you may use to remotely manage the WEBSHARE 111U. Interface Select the access interface. Choices are LAN, WAN and Both...

  • Page 64: Filter

    9.2 Filter In this section is possible to set different filtering type, based on IP/MAC, URL or Application. 9.2.1 IP/MAC Filter...
  • Page 65 Field Description IP Filter set Editing IP Filter set Index This is item number Interface Select which channel (PVC) to configure Direction Select the access to the Internet (“Outgoing”) or from the Internet (“Incoming”) or Both IP Filter Rule Editing IP Filter Rule Index This is item number Rule Type...
  • Page 66 be configured by an advanced user Destination Port This is the Port or Port Ranges that defines the application Protocol It is the packet protocol type used by the application, select either TCP or UDP or ICMP 9.2.2 Application Filter Field Meaning Application Filter...
  • Page 67 9.2.3 URL Filter Field Meaning Active Select Active to enable URL Filter. URL Index This is item number. Allow you to prevent users on your network from accessing particular websites by their URL.

  • Page 68: Snmp

    9.3 SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. WebShare 111U supports SNMP agent functionality which allows a manager station to manage and monitor the router through the network. Field Description Get Community...
  • Page 69 Both the user’s Operating System and the relevant application must support UPnP in addition to the router. Windows XP and Windows Me natively support UPnP (when the component is installed), and Windows 98 users may install the Internet Connection Sharing client from Windows XP in order to support UPnP. Windows 2000 does not support UPnP.

  • Page 70: Dynamic Dns

    9.5 Dynamic DNS The Dynamic DNS function allows you to alias a dynamic IP address to a static hostname, allowing users whose ISP does not assign them a static IP address to use a domain name. This is especially useful for hosting servers via your ADSL connection, so that anyone wishing to connect to you may use your domain name, rather than having to use your dynamic IP address, which changes from time to time.

  • Page 71: Advanced Setup

    User Type your user name Password Type the password assigned to you Wildcard Support Select this check box to enable DYNDNS Wildcard 10. Advanced Setup This section will show how to configure static route, virtual server, Adsl line module and firewall. 10.1 Routing If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet.
  • Page 72 Metric It represents the cost of transmission for routing purposes. The number need not be precise, but it must be between 1 and 15 Device Media/channel selected to append the route Counter for access times Edit Edit the route; this icon is not shown for system default route Drop Edit the route;...

  • Page 74: Nat

    10.2 NAT The NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet. The default setting is Dynamic NAPT. It provides dynamic Network Address Translation capability between LAN and multiple WAN connections, and the LAN traffic is routed to appropriate WAN connections based on the destination IP addresses and Route Table.

  • Page 75: Ip Address Mapping

    Assigned Numbers Authority), and these are referred to as “well-known ports”. Servers follow the well-known port assignments so clients can locate them. If you wish to run a server on your network that can be accessed from the WAN (i.e. from other machines on the Internet that are outside your local network), or any application that can accept incoming connections (e.g.
  • Page 76 multiple local IP addresses to one global IP address. This is equivalent to Many to One (i.e., PAT, port address translation) • Many-to-Many Overload: This is mode maps multiple local IP addresses to shared global IP addresses • Many-to-Many No Overload: This is the mode maps each local IP address to unique global IP addresses •...

  • Page 77: Qos

    can configure the virtual server IP address manually, but it must still be in the same subnet as the router. 10.5 QoS Quality of Service (QoS) helps to prioritize data as it enters your router. By attaching special identification marks or headers to incoming packets, QoS determines which queue the packets enter, based on priority.
  • Page 78 The following table describes the labels in this screen: Field Descriptions RULE...
  • Page 79 Rule Index Select 16 different rules, each rule’s detail can be set and saved. Active Select QoS is activated or deactivated. Application Select 11 different applications: IGMP, SIP, H.323, MGCP, SNMP, DNS, DHCP, RIP, RSTP, RTCP, RTP. Physical Port Once you select the application, the associated ports will be displayed.

  • Page 80: Adsl

    DSCP Marking Select the remarking value of DSCP. 802.1p Marking Select the remarking value of 802.1p. Queue# Select four types of Queue: Low, Medium, High, Highest. 10.6 ADSL Field Description ADSL Mode The default setting is Auto Sync-UP. This mode will automatically detect your ADSL, ADSL2+, ADSL2, G.dmt, G.lite, and T1.413.

  • Page 81: Manteinance

    11. Manteinance 11.1 Administration In factory setting, the default password is atlantis, and that for user is also password. You can change the default password to ensure that someone cannot adjust your settings without your permission. Every time you change your password, please record the password and keep it at a safe place.

  • Page 82: Time Zone

    Field Description New Password Type the new password in this field Confirm Password Type the new password again in this field 11.2 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network.

  • Page 83: Firmware

    Time Zone Choose the time zone of your location. This will set the time difference between your time zone and Greenwich Mean Time (GMT) Daylight Saving Select this option if you use daylight savings time NTP Server Enter the IP address of your time server. Check with your Address ISP/network administrator if you are unsure of this information 11.3 Firmware...

  • Page 84: Sysrestart

    Field Description New Firmware Type in the location of the file you want to upload in this Location field or click Browse to find it. New RomFile Romfile means the configuration file. Type in the location of Location the file you want to upload in this field or click Browse to find it.

  • Page 85: Diagnostic

    If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings. You may also reset your router to factory settings by holding the small Reset pinhole button on the back of your router in for 10-12 seconds whilst the router is turned on.

  • Page 86: Status

    12. Status 12.1 Device Info Field Description Device Information F/W Version This is the Firmware version MAC Address This is the MAC Address...

  • Page 87: System Log

    LAN Information IP Address LAN port IP address IP Subnet Mask LAN port IP subnet mask DHCP Server LAN port DHCP role - Enabled, Relay or disabled WAN Information Status “Not connected” or “Connected” Virtual Circuit There are eight groups of PVC can be defined VPI: The valid range for the VPI is 0 to 255 VCI: The valid range for the VCI is 32 to 65535 Connection Type...

  • Page 88: Statistics

    12.3 Statistics Read-only information here includes port status and packet specific statistics. Also provided are "Transmit Statistics" and "Receive Statistics". ETHERNET Field Meaning Interface This field displays the type of port Transmit Frames This field displays the number of frames transmitted in the last second Transmit Multicast...
  • Page 89 Receive total PDUs This field displays the number of total PDU received in the last second Receive total Error This field displays the number of total error received in the Counts last second...

  • Page 90: Appendix A: Troubleshooting

    APPENDIX A: Troubleshooting This chapter covers potential problems and the corresponding remedies. A.1 Using LEDs to diagnose problems The LEDs are useful aides for finding possible problem causes. A.1.1 Power LED The PWR LED on the front panel does not light up. Steps Corrective Action Make sure that the ADSL Router’s power adaptor is connected to the...
  • Page 91 Steps Corrective Action Check the telephone wire and connections between the ADSL Router DSL port and the wall jack. Make sure that the telephone company has checked your phone line and set it up for DSL service. Reset your ADSL line to reinitialize your link to the DSLAM. For details, refer to the Maintenance chapter (web configurator) or the System Information and Diagnosis chapter.
  • Page 92 Make sure that there is not an console session running. Check that you have enabled web service access. If you have configured a secured client IP address, your computer’s IP address must match it. Refer to the chapter on remote management for details.
  • Page 93 section for uploading a configuration file via console port. The default username is “admin”. The default password is “atlantis”. The Password and Username fields are case-sensitive. Make sure that you enter the correct password and username using the proper casing. It is highly recommended to change the default username and password.
  • Page 94 Authentication may be through the user name and password, the MAC address or the host name. username password apply PPPoE PPoA encapsulation only. Make sure that you have entered the correct Service Type, User Name and Password (be sure to use the correct casing).
  • Page 95 connection. Refer to Section A.7 for instructions on checking your WAN connection. See also the Section A.4. A.9 Remote Node Connection I cannot connect to a remote node or ISP. Steps Corrective Action Check WAN screen to verify that the username and password are entered properly.

  • Page 96: Appendice B: Technical Specifications

    APPENDICE B: Technical Specifications Protocols IP, NAT, ARP, ICMP, IGMP, DHCP(server, client and relay), RIP1/2 , SNTP client, UPnP, Telnet server, SNMP LAN Port 1 x RJ45 10/100 Base-T port USB Port 1 porta USB v1.1 WAN Port RJ-11 (1 port ADSL) Button Reset/Power Switch LEDs...

  • Page 97: Appendice C: Support

    If you have any problems with the WebShare 111U, please consult this manual. If you continue to have problems you should contact the dealer where you bought this ADSL Router. If you have any other questions you can contact the Atlantis Land company directly at the following address:...
