I-Storm
PCI ADSL Modem
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Atlantis Land I-Storm

Summary of Contents for Atlantis Land I-Storm

  • Page 1 I-Storm PCI ADSL Modem User’s Manual...

  • Page 3: Table Of Contents

    1.1 I-Storm PCI ADSL Modem Features 1.2 Package Contents 1.3 Information from ISP CHAPTER 2 2.1 Installing I-Storm PCI ADSL Modem 2.2 Installing I-Storm PCI ADSL Modem Drivers 2.2.1 For Windows 98 2.2.2 For Windows Me 2.2.3 For Windows 2000 2.2.4 For Windows XP CHAPTER 3 3.1 I-Storm PCI ADSL LAN Adapter Configuration...

  • Page 5: I-Storm Pci Adsl Modem Features

    1.1 I-Storm PCI ADSL Modem Features I-Storm PCI ADSL Modem provides the following features: ♦ PCI modem for broadband ADSL. ♦ Downstream data rate up to 8 Mbps and upstream up to 1 Mbps. ♦ Plug and Play for Microsoft Windows 98 (SE), 2000, Me, NT4.0 and XP.

  • Page 6: Information From Isp

    If your ISP provides PPPoE or PPPoA connection method, please select “I-Storm PCI ADSL WAN Adapter” to install driver. If your ISP provides RFC1483 Bridged or Routed or IPoA, please select “I- Storm PCIADSL LAN Adapter” to install driver.

  • Page 7: Chapter 1 Introduction

    RFC1483 VPI/VCI, VC-based/LLC-based multiplexing, IP address, Subnet mask, Gateway address, and Routed Domain Name System (DNS) IP address (it is fixed IP address). VPI/VCI, IP address, Subnet mask, Gateway IPoA address, and Domain Name System (DNS) IP address (it is fixed IP address). Chapter 1 Introduction...

  • Page 8: Installing I-Storm Pci Adsl Modem

    Chapter 2 Installation 2.1 Installing I-Storm PCI ADSL Modem Please refer to the following instructions: First, you need to prepare your phone line and your phone devices at your premises. ADSL and telephone services share the same copper wire to carry their respective signals, a filtering mechanism must be used to avoid mutual interference.

  • Page 9: Chapter 2 Installation

    Chapter 2 Installation 4. Unscrew the “Retaining Screw” and remove and discard the “Expansion Slot Cover” from any unused PCI slot ( PCI slots are usually white in colour). 5. Gently and evenly insert the PCI modem card into your empty PCI slot.

  • Page 10: Installing I-Storm Pci Adsl Modem Drivers

    8. Connect the ADSL/phone line to the connector port on the modem card and plug the other end of the cable into your phone line. 2.2 Installing I-Storm PCI ADSL Modem Drivers 2.2.1 For Windows 98 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected.
  • Page 11 “Specify a location”. Click “Browse…” to specify the driver directory such as D:\Driver\SO\LAN for installing I-Storm ADSL Adapter D:\Driver\SO\WAN for installing I-Storm PCI ADSL WAN Adapter. (Please refer Information from ISP section for more details.) Click “OK” and then “Next>” to continue.
  • Page 12 I-Storm PCI ADSL modem 4. Continuing through the Wizard, click the “Next >” button. Windows will start copying files to your system. Then, click “Finish”. 5. You will see the following screen prompting for the path of the Windows source files. Please specify a location.

  • Page 13: For Windows Me

    6. I-Storm PCI ADSL Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. 7. I-Storm PCI ADSL Modem icon is installed in the Control Panel. Go to the Device Manager, the “I-Storm PCI ADSL LAN Adapter”...
  • Page 14 I-Storm PCI ADSL modem 3. Continuing through the Wizard, Windows will start copying files to your system. Then, click “Finish”.

  • Page 15: For Windows 2000

    4. I-Storm PCI ADSL Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. 5. I-Storm PCI ADSL Modem icon is installed in the Control Panel. Go to the Device Manager, the “I-Storm PCI ADSL LAN Adapter”...
  • Page 16 “Next>”. 3. Click “Browse…”. In the Locate File window, specify the driver directory such as D:\Driver\SO\LAN\CxtCAFEU for installing I-Storm PCIADSL LAN Adapter or D:\Driver\SO\WAN\CxtCAFEU for installing I-Storm PCI ADSL WAN Adapter. (Please refer Information from ISP section for more details.) Click “Open” and then “Next>“...

  • Page 17: For Windows Xp

    6. I-Storm PCI ADSL Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. 7. I-Storm PCI ADSL Modem icon is installed in the Control Panel. Go to the Device Manager, the “I-Storm PCI ADSL LAN Adapter”...
  • Page 18 I-Storm PCI ADSL modem...
  • Page 19 Anyway” to go on. Then, click “Finish”. 5. Wait a few moments. Windows will show that the new device, I-Storm PCI ADSL LAN (or WAN) Adapter, has been detected. Select “Install from a list or specific location”. Click “Next >”...
  • Page 20 9. I-Storm PCI ADSL Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. 10. I-Storm PCI ADSL Modem icon is installed in the Control Panel. Go to the Device Manager, the “I-Storm PCI ADSL LAN...
  • Page 21 Follow the instructions below to configure your I-Storm PCIADSL Modem. Click I-Storm PCI ADSL Modem icon in the Control Panel or ADSL Configuration icon on the desktop. The status of ADSL connection will be displayed. 2. Press [Alt]+[P] on keyboard, the following figure appears.

  • Page 22: I-Storm Pci Adsl Lan Adapter Configuration

    3. Select the Protocol Setup tag, please set the value of “VPI”, “VCI” and “Encapsulation Mode”. Then, click “OK”. 3.1 I-Storm PCI ADSL LAN Adapter Configuration 3.1.1 For Windows 98 / Me Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab.

  • Page 23: Chapter 3 Configuration

    2. Select TCP/IP → I-Storm PCI ADSL LAN Adapter. Then, click Properties. 3. Select the IP Address tab. In this page, click the Specify an IP address radio button and enter the “IP address” and “Subnet Mask” provided by your ISP.
  • Page 24 I-Storm PCI ADSL modem 5. In the DNS Configuration page. Click the Enable DNS radio button. Enter the “Host” name and “DNS Server IP address” provided by your ISP. Then, press the Add button.

  • Page 25: For Windows 2000 / Xp

    3.1.2 For Windows 2000 / XP Go to Start / Settings / Control Panel. In the Control Panel, double-click Connections. Right–click on Local Area Connection that is using the I-Storm PCI ADSL LAN Adapter and then click “Properties”. Chapter 3 Configuration Network Dial-up...
  • Page 26 I-Storm PCI ADSL modem Select “Properties”. Internet Protocol (TCP/IP). Then, click...
  • Page 27 Chapter 3 Configuration Select Use the following IP address, and then enter the “IP address”, “Subnet mask”, and “Default gateway” provided by your ISP. Select Use the following DNS server addresses and then enter the provided DNS server IP address.

  • Page 28: I-Storm Pci Adsl Wan Adapter Configuration

    I-Storm PCI ADSL modem 3.2 I-Storm PCI ADSL WAN Adapter Configuration Click ADSL Easy Dialup icon on the desktop. Then, the following window appears. Enter the “Username” and “Password” provided by your ISP. Let the Phone number field be blank.
  • Page 29 Chapter 3 Configuration Click Connect and get ready to surf the Internet!

  • Page 30: Appendix (Product Support)

    Product Support If you have any problems with the I-Storm PCI ADSL Modem, please contact the dealer where you bought this product. If you have any other questions you can contact the Atlantis Land company directly at the following address:...
