Dear Customers
Thanks for purchasing this TFT-LCD TV/Monitor. We strongly recommend
that you carefully read the safety and operation instructions before
operating your TV/Monitor. FOLLOW INSTRUCTIONS AND HEED ALL
WARNINGS

Safety information

__________________________________________________
Caution:
The lightening flash with arrowhead symbol, within an equilateral
voltage" within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to the persons.
The exclamation point within an equilateral triangle is intend to
Correct disposal of this Product
(Waste Electrical & Electronic Equipment (WEEE)
The crossed out "Wheelie bin" is intended to show that this
appliance must not be placed with ordinary household waste at the
end of its useful life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please keep
separate from other household waste and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where you
purchased the product, or their local government office for details of
where and how you can take this item for environmentally safe
re-cycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product must not be
mixed with other commercial wastes for disposal
triangle, is intended to alert the user to the presence of un
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
–insulated "dangerous
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TFT LCD TV/Monitor and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Akura TFT LCD TV/Monitor

  • Page 1: Safety Information

    Dear Customers Thanks for purchasing this TFT-LCD TV/Monitor. We strongly recommend that you carefully read the safety and operation instructions before operating your TV/Monitor. FOLLOW INSTRUCTIONS AND HEED ALL WARNINGS Safety information __________________________________________________ Caution: The lightening flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un –insulated “dangerous voltage”...
  • Page 2 Precautions ________________________________________________________ Please read the below precautions carefully before operating the unit. Power cord protection: Never use your appliance if the power cord has been damaged. Do not put anything on the power cord, and keep the power cord away from where people can easily trip over it.
  • Page 3 Servicing: If the LCD TV/Monitor does not operate normally – In particular, if there are any unusual sounds or smells coming from the unit – unplug it immediately and contact an authorized dealer or service center. Make sure the service technician uses authorized replacement parts or their equivalents.
  • Page 4: Table Of Contents

    Car Cord RCA cable (Optional) Table of contents View of the TV/Monitor Remote control reference guide (1) Remote control function (2) Remote control battery installation and cautions III. Installation and connection TV/Monitor screen operation (1) Basic operation (2) View of the TV plays (3) View of the AV signal sources (4) View of the TELETEXT program (Optional, if the unit has this function.)
  • Page 5 View of the monitor Side view Front view Back view Remote sensor 12. VGA socket Power indication light 13. SCART socket Headphone jack 14. S-video socket CH+ / Up button 15. Audio in (right) socket CH- / Down button 16. Audio in (left) socket VOL up / RIGHT button 17.
  • Page 6 II. Remote control reference guide (1) Remote control function 1. DVD open/close 2. Video out mode button 3. SLEEP button 4. 0-9 Numerical button 5. Program play button 6. Volume down button 7. Unit system menu button 8. Display status message button 9.
  • Page 7 ● TELETEXT BUTTONS Name Function Name Function To select TXT/TV mode To show the sub page Enter into TXT list mode Freeze display Display the hidden INDEX Menu display information Screen zooming Page display or cancel Display red screen GREEN Display green screen YELLOW Display yellow screen...
  • Page 8: Installation And Connection

    batteries into the fire. 3. Always replace both batteries at the same time. Never mix new and old batteries or batteries of a different type. 4. If you don‟t intend to use the remote controller for an extended period, remove the batteries to prevent possible leakage and corrosion. Notes: Do not drop, apply shock or step on the remote control.
  • Page 9: Tv/Monitor Screen Operation

    Outdoor Antenna Connection: UHF antenna 75Ω Co-axial cable Co-axial antenna plug Antenna Ω Co-axial input cable Connect the audio sources (Including DVD, VCDR, CAMCORDER and PC) to the AUDIO input jacks „L‟ and „R‟. Connect the video source to the VIDEO socket by RCA cable. If the video source has a SCART output socket, you can connect the signal to the monitor by the SCART cable.
  • Page 10 The Picture settings, Sound settings, and previous channel will be memorized when you switch off the TV to standby. The TV/Monitor will re-start in the previous state when you switch on it again. If you unplug the power cord to cut off the power supply completely, all previous setting will be lost.
  • Page 11 Select the required input to select the AV signal. Input Source Press P+ or P- button to select source, then press Video V + button to confirm your selection. Or press DVD S-Video Button on the remote control to select DVD source directly.
  • Page 12: Menu Setting And Adjustment

    V. Menu setting and adjustment VIDEO MODE SETTING Press the MENU button on the remote control, there will be a menu displayed on the screen as below: Video Picture Mode : Standard Brightness Contrast Saturation Sharpness Color Temp. : Standard Advanced Move Select...
  • Page 13 screen: Image Auto Config. Image Position Phase: Clock: 1344 Move Select Exit 1.The cursor will on the line of “Auto Config”, press the V+ button, the following will be displayed on the screen, then select Yes to enter into auto configuration as follows: Auto Config.
  • Page 14 Image Position Move Select Exit After setting, press the MENU button to return to the root menu or exit the setting AUDIO MODE SETTING Press the MENU button on the remote control, and then press the P- button to select the Audio setting, the Menu will be shown as below: Audio Bass Treble...
  • Page 15 the sound mode from Bass, Treble, Balance. After you select the sound mode, use the V- or V+ button to adjust the value of each item from 0 to 100 or Balance from -50 to 50 for each sound mode. After setting, press the MENU button to return to the root menu or exit the setting menu.
  • Page 16 TUNER/CHANNEL MODE SETTING (FOR TV MODE ONLY) Press the MENU button to display the menu, and then use the P- button to select the Tuner/Channel setting icon, the following menu will display in the screen: Tuner/Channel Channel No. Color System AUTO Audio System Skip...
  • Page 17: Auto Search

    CH NO:9 Band: VHF-L Auto search FREQ: 175.15 MHz As shown on the menu, the TV will automatically search for stations. When searching, press the MENU button to cancel searching. After the search is completed the TV will show the programme in location 1. The TV stations will be in “found”...
  • Page 18 the stations in the correct order i.e. BBC1(1), BBC2 (2), ITV (3), CH4 (4), CH5(5). Select the “Channel Swap”, and then press the V+ button, the screen will display: Tuner/Channel Swap From Swap To Perform Swap Move Select Exit In the menu, the words “Swap From” indicates the current station and 6 is the station number;...
  • Page 19: Dvd Player Operation

    be shown on the screen as below: Options Language Reset Blue Screen OSD Timeout :10 Seconds Keypad Lock :OFF Menu Background :Transparent Move Select Exit Press P-/P+ or V+/V- to select or set each item, select “Language” first, press V+ or V- button, it can be set to English, French, German, Spanish, Portuguese, Italian, Russian or Dutch.
  • Page 20 player and it will be read automatically. Note DO NOT FORCE THE DISC INTO THE SLOT, it may have a disc inside already. Press ”OPEN/CLOSE” button of the remote control or the button on the unit ,the disc will be ejected automatically HOW TO SELECT THE TRACK If you want to play the second track or chapter, please press the number button “2”...
  • Page 21 DVD video player magnifies the center or the picture at 2x, 3x, 4x, 1/2, 1/3, 1/4 of the normal picture. In the ZOOM mode, you can use / / / buttons to move the picture for optimum viewing. d. REPEAT PLAY You can use the REPEAT button to repeat a section playing under normal conditions.
  • Page 22 Caution: Do not increase volume of the TV or amplifier when the system is on MUTE. There are chances of the speakers getting damaged when the sound is resumed. g. RANDOM PLAYING (RANDOM) Music Files. Press the STOP button first, then press the RANDOM button on the remote control to play the disc in random order of song titles or picture scenes.
  • Page 23 04 -- 09-- 14 -- 19 -- 05 -- 10 -- 15 -- 20 -- PREV Exit Start NEXT Input the numbers to select the title and chapter (track) you want, and / / / pressing the buttons to move the cursor, then input the next one.
  • Page 24 l. SELECTING SUBTITLES This DVD video player allows you to display the subtitles from those included on the disc. Press the SUBTITLE button during playback, you have the option to select a preferred subtitle from those included on the DVD/MPEG4 video disc.
  • Page 25 n. CUSTOMIZING THE FUCTION SETTINGS This DVD video player allows you to customize the performance to your personal preference. DISPLAYING THE SETUP MENU SCREEN: The SETUP MENU screen asks you to select a setting category from GENERAL SETUP, AUDIO SETUP and PASSWORD SETUP. The selected category will provide you the setting details on the TV screen.
  • Page 26: Other Operation

    AUDIO SETUP Choose AUDIO OUT mode as SPEAKER SETUP, AUDIO SETUP, to get the best sound as follows: PASSWORD SETUP (INITIAL PASSWORD 1369) VII. Other Operation a. Earphone operation This unit possesses an earphone socket. Plug the earphone into the socket and adjust the volume.
  • Page 27: Trouble Shooting

    VIII. Trouble shooting Should the unit not function, please check the system according to this table to find out the possible problem. If you still can‟t solve the problem, please call the Customer Help line. General SYMPTOM POSSIBLE CAUSE SOLUTION Ensure all plugs are Dead.
  • Page 28 No functions operating System may be Turn off the power and “locked up” allow 5 seconds before reapplying power No, or intermittent Remote batteries Replace batteries in Remote functions exhausted. remote control. Objects in line of Remove any object in operation line with sensor Disc not accepted in...
  • Page 29 Incorrect region code This player only accepts “Region 2” discs Picture freezes or Dirty or damaged disc. Clean disc and inspect breaks up for damage. Sound in wrong Incorrect language Set language in menu language setting PC Mode No display from PC PC Video source may See display modes list be set incorrectly...
  • Page 30: Maintenance

    (4) Because of a sudden change in temperature or humidity, or when warm air comes into contact with any cold parts in the unit, condensation may form. When condensation forms inside, the unit may not function well. Once condensation disappears, the unit will return to normal functioning.
  • Page 31: Specification

    qualified service personnel. Specifications Screen size, visible 15 inch Screen format Resolution 1024 * 768 Minimum contrast ratio 500:1 Minimum brightness 2500 cd/m² Display colors 16.2M Minimum viewing angle 170° (horizontal) / 160° (vertical) Maximum response Time 16 ms Minimum lifetime background light 50,000 hours Video color systems PAL/NTSC3.58/NTSC4.43/SECAM...
  • Page 32: Display Modes

    Audio R/MONO Input Composite video, RGB, Audio L+R Scart Output Composite video, Audio OSD language English//French/Spanish/ Italian, etc Audio output 1.5W * 2 Gross weight 5.8 Kgs Power requirement DC 12V 5A, AC100~250V, 50Hz/60Hz Power Consumption Max 50W XII. Display modes Resolution Horizontal Freq.
  • Page 33 standard. This is not, however, an error. You can improve this situation by altering an automatic setting or by manually changing the phase setting and the pixel frequency menu. If you switch off the TV/monitor, interference lines can occur on your screen.
