- Page 1 AAMT15LCD Instruction Manual for LCD -TV >>>...
-
Page 2: Instruction Manual
Electric Engineering Society and national relevant standards. Thank you for your buying and using AKURA products. Check to see if the accessories are complete after opening the box. Read the Instruction Manual carefully before connecting the parts and the set... -
Page 3: Table Of Contents
Table of Contents Important Safety Instructions ..............1-3 Accessories ....................4 Connections.................... 5-6 Front Control Buttons ................7 Power Supply .................... 8 Remote Control ..................9-10 TV Operation ....................11 11-12 First time Installation ................... 12-13 Station Sorting ..................... Manual Tuning ....................14-15 Fine Tuning .................... -
Page 4: Important Safety Instructions
Important Safety Instructions CAUTION: TO REDUCE THE RISK OF CAUTION ELECTRICAL SHOCK, DO NOT REMOVE RISK OF ELECTRIC COVER(OR BACK).NO USER SERVICEABLE SHOCK DO NOT OPEN. PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lighting flash with arrowhead symbol,with an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”... - Page 5 CAUTION: 1. Read Instructions - All the safety and operating instructions should be read before the product is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the product and in the operating instruc- tions should be adhered to.
- Page 6 damage the appliance. 11. Do not use the television set near water ... for example, near a bathtub, washbowl, kitchen sink, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
-
Page 7: Accessories
Accessories Quality guarantee card Quality guarantee card The master and the base Power adaptor VGA wire Instruction manual Audio-frequency cable Instruction manual Remote controller Av to scart converter... -
Page 8: Connections
Connections 1. TV Aerial connection (75 ohms) 2. Stereo Headphones 3. Stereo Audio Input 4. Video Input (CVBS) 5. “Y” 6. Pb/Cb 7. Pr/Cr 8. S-Video Input 9. VGA Computer Input 10. DC Input (AC/DC Adaptor) 12V Aerial Connection... - Page 9 Connections to a Computer Switch off the power to the computer and Tv Connect one end of the VGA line to the display card and the other to the Connect the two ends of the audio cable to the sound card of the PC and the audio input socket respectively.
-
Page 10: Front Control Buttons
Front Control Buttons 1. Source: This selects the video source, TV, PC, VIDEO, S-VIDEO, YUV. 2. Menu: Press the [MENU] button to show the main [MENU] on the screen and select the items to be adjusted. 3. Vol: Volume select. Press this key and then use the keys to adjust volume. -
Page 11: Power Supply
Power Supply How to Connect/Disconnect the Power Supply Insert the plug of the12V DC power supply into the 12V input socket of the TV set. To turn the Tv on press the ON/OFF button on the Tv or the Remote control. -
Page 12: Remote Control
Remote Control Mute ......Turns the Sound On and Off. ON/OFF ....Switches the Tv to and from Standby. Source .....Selects the input source. Digit Buttons ...Selects channel numbers directly. Sys ......Changes the “Sound System” used in conjunction with the V+/V- buttons. Colour ......Selects the Screen colour content. -
Page 13: Remote Control
Auto ......Adjust the picture in best position automaticaly.(In PC mode) Display ....Shows the status of the Tv Sleep ......Selects Sleep Timer, use in conjunction with Vol +/- Exit......Exits all menu and sub – menu screens When you receive the remote control it will require the battery to be fitted. Slide off the battery cover and place the battery (CR2025) with the + side facing upwards. -
Page 14: Tv Operation
TV Operation First Time Installation Ensure the Tv is connected to the Power supply and suitable aerial. Plug the power supply in to the mains connector and switch the Tv on, with either the remote control or the button on the front of the Tv. Select Tv using the “Source”... -
Page 15: Station Sorting
Using the “Menu” button enter that menu and with the “ ”button move the highlight down to “Auto Search” and press the “Menu” button, see “fig 3”, Fig 3 now press the “ ” button. The Tv will now begin to search all bands, see “fig 4”. - Page 16 Using the “Menu” button enter that menu and with the “ ”button move the highlight down to “Prog Edit” see “fig 5”, Fig 5 Now press the “Menu” button, Current Prog will now be highlighted. Press the “Menu” button again and the Programme number will be in red, see “fig 6”.
-
Page 17: Manual Tuning
Manual Tuning Occasionally you may wish to add another station to the “tuning list”. This may be a VCR or Tv game or another Tv station opening in your area. Press the “Menu” button, this will show the menu, see “fig 1” Using the “... -
Page 18: Skip Channels
Using the “Menu” button enter that menu and with the “ ”button move the highlight down to “Fine Tune”. Press the “Menu” button and using the “ ” buttons, adjust the tuning as required. To exit this menu press “Exit” Skip. -
Page 19: Picture Adjustments
Press the “Menu” button, this will show as “fig 8” Fig 8 Using the “ ” buttons, select the sound system you require. Press the “Menu” button or Exit button to exit the menu. Picture Adjustments. ( TV, VIDEO, S-VIDEO, YUV) To adjust the picture levels to your requirements. - Page 20 Contrast. This adjusts the ratio of black to white picture, adjust this to your taste. Use the “ and ” buttons to select “Contrast”. Press the “Menu” button and then use the “ ” buttons to adjust the level. Press the “Menu” button once to exit that adjustment, or use the “Exit” button once.
-
Page 21: Sound Adjustments
Sound Adjustments. ( all modes). To adjust the sound levels to your requirements. Volume. This adjustment is not in the menu system and is adjusted with the Remote control or the “VOL” button and “ ” buttons, on the front of the Tv. Press the “Menu”... -
Page 22: Set Up
Treble. Adjusts the sound for a “brighter” sound. Use the “ and ” buttons to select “Treble”. Press the “Menu” button and then use the “ ” buttons to adjust the level. Press the “Menu” button once to exit that adjustment, or use the “Exit” button once. -
Page 23: Language
Language. This sets the OSD (On Screen Display) language. (normally default to Eng- lish). Use the “ and ” buttons to select “Language”. Press the “Menu” button and then use the “ ” buttons to adjust the required Language. Press the “Menu” button once to exit that adjustment, or use the “Exit” button once. -
Page 24: Blue Screen
Blue Screen. When in “no signal” conditions, e.g, the aerial lead is unplugged, or No AV inputs, the screen may be set to display “Blue”. Use the “ and ” buttons to select “Blue Screen”. Press the “Menu” button and then use the “ ”... -
Page 25: Pc Operation
PC Operation. (VGA). Connect the Tv to your PC as described on Page 6. Turn on the PC and the Tv monitor.Using the “Mode” button on the Remote Control or the “Source” button on the Tv, select PC.You should now see the PC display screen. -
Page 26: Set Up
4. When the “Auto Config” is completed the menu will disappear. Other Menu Choices. Should the screen not adjust to your liking, you may adjust manually, using the “Location” menu.To enter the “LOCATION” menu Press the “Menu” button, this will show the menu, see “fig 14”.Using the “ ” button move the highlight on the left side of the menu to “LOCATION”... - Page 27 Use the “ and ” buttons to select “Reset”. Press the “Menu” button and then to Tv will reset to the default condi- tion. To exit the menu totally, press the “Exit” button twice. Picture Adjustments. (PC mode). To adjust the picture levels to your requirements. Press the “Menu”...
-
Page 28: Wall Mounting
Wall Mounting You may mount this Tv on the wall using the desk existing stand. Place the Tv in the approximate location, where you wish to mount it on the wall and mark with a pencil. Place the Tv on its face and carefully turn the base bracket upwards, until the base is parallel with the cabinet back. -
Page 29: Adjusting Screen Angle
Adjusting Screen Angle. When you adjust the screen angle, press the base with one hand and the set with another one and push it back and forth to get the best angle as it shows in the following figure. About 5 About 25 Using forbiden area Note: Rotate forward or backward... -
Page 30: Display Modes
Display Modes The follow table shows the display modes you can have on your machine Resolutio ratio Line frequency(kHz) Field frequency (Hz) Point frequency(MHz) 28.80 60.00 18.43 640*480 34.56 72.00 22.12 36.00 75.00 23.04 36.00 60.00 28.80 800*600 43.20 72.00 34.56 45.00 75.00... -
Page 31: Trouble Shooting Guide
Trouble Shooting Guide If you experience trouble with this Tv please consult this help guide before calling the “Technical Help Line”. General operation Symptom Possible cause Remedy Check all connections to the No power. No leds lit. No power connected to the Tv. Tv. -
Page 32: Product Specification
Product Specifications Model........AAMT15LCD Tuning.range........45.Mhz.–.870.Mhz.(Band.1,.Band.3,.UHF) Tuning.Mode........Frequency.Synthesizer... Inputs..........TV,.AV,.S-Video,.VGA,.“Y,.Pb/Cb,Pr/Cr”(non-progressive) Outputs..........Headphones Screen.Panel.size......15”.Diagonal Contrast.ratio.(typical)......400.:.1 Bright.intensity.(typical)......250.nits Dot.pitch..........0.297.mm Number.of.colours......16,777,216 Visual.angle:.Horizontal......170.deg Visual.angle:.Vertical......170.deg Horizontal.frequency......30.–.62.Khz Vertical.frequency.......50.–.75.Hz Optimum.resolution.ratio....1024.x.768 TV.system...........PAL.(.NTSC.AV.input) Sound.Systems........“I”,.“B/G”,.“D/K”,”MN” Speakers..........2.x.2.2.W.(8.ohms) Temperature........0.–.40.deg.C Average.life.span.of.the.display..50,000.Hrs Size(cm)..........36.(L).x.18.3.(W),.34.5.(H) Weight..........3.8.Kg Power.supply........12V.DC.4A.. Mains.Adaptor........AC.input.100.–.240V.AC.50.–.60.Hz.1.0.A... Power.consumption......30W.Max *.No.notice.will.be.given.in.case.of.a.change.in.the.design*...
