Meet Your Pedometer
We call him Buster
Hello
I'm Buster and I'll be your pedometer.
I promise to be with you through thick
and thin. Stick with me and you'll like
what you see. I'll help you bust a move.
Bust off inches. And bust through your
barriers.
So wear me. Walk with me.
Take me with you!
Getting to know me
Put me on (oh, you're putting me ON!)
Hold my belt clip open, GENTLY PLEASE.
Slide me onto your belt. I also work well on
the top edge of pants and skirts—if you wear
me there, be sure I fit snugly and on the level,
above one knee.
NOTE: I've been known to get confused when
I'm not worn correctly, and I won't work if
I am slumped over or on my side. Believe me,
I really want to give you all the step credits you
deserve. So, if you happen to be a person of
the larger persuasion, you may find it helpful
to wear me farther back on your body, toward
one hip.
Also, my cover must be closed, or I just won't
work. Don't try to talk me into any other way.
My mind is as closed as my cover.
And PLEASE don't drop me! You might
end up hurting more than just my feelings.
©2006 Shaklee Corporation. Distributed by Shaklee Corporation, Pleasanton CA, 94588. 06-460 (Rev 10/06)
My display shows your step count since last reset,
up to 100,000 steps.
White Button: RESET
Viewing your results
Once you put me on with the cover closed,
I will automatically begin to record your steps.
Resetting me
To reset: press and hold the white RESET button
for at least 2 seconds.
Replacing my battery
When my display dims or goes blank, it is time
to replace the battery. I use one Type L1142
(LR43) 1.5 volt alkaline battery, or one type 1132S0
(SR43) silver oxide battery for longer life.
1. Insert a dime or penny into the slot on the front
of my case. Twist counterclockwise 1/8
loosen and remove the battery door.
2. To remove the battery, use a pointed object,
such as a pen, to lift the edge of the battery,
using the small slot at bottom right of battery
compartment. Now, shake the battery out of
its slot.
3. Hold the new battery and turn it so the "+" side
is facing up. Now push it down (initially at an
angle towards the back of the case) and back
into the battery recess, until it is all the way inside.
4. Reinstall the battery cover by gently sliding the
cover around until it pops into place and sits
flush with the case. Then twist the battery cover
only 1/8th turn in the clockwise direction to tighten.
My warranty info
5-Year, Limited No-Proof-of-Purchase Warranty
Model: AE2720STEP with TW17 PedometerEngine.
Warranty service is free for the first year of
ownership. Warranty service is available for a $10
fee thereafter. See label on the inside cover of
your pedometer for warranty date.
For warranty service, please contact:
support@accusplit.com or call 925.290.1900
or visit support.accusplit.com/shaklee.html
©2006 ACCUSPLIT Made in Taiwan.
steps
turn to
th
™
