Aastra SIP 480i Administrator's Manual

Aastra SIP 480i Administrator's Manual

Sip ip phone release 1.0
Hide thumbs Also See for SIP 480i:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Administrator's Manual
SIP IP
PHONE
RELEASE # 1.0
ADMINISTRATOR
GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIP 480i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aastra SIP 480i

Summary of Contents for Aastra SIP 480i

  • Page 1 SIP IP PHONE RELEASE # 1.0 ADMINISTRATOR GUIDE...
  • Page 2 Aastra Telecom will not accept liability for any damages and/or long distance charges, which result from unauthorized and/or unlawful use. While every effort has been made to ensure accuracy, Aastra Telecom will not be liable for technical or editorial errors or omissions contained within this documentation.

  • Page 3: Table Of Contents

    480i IP Phone Set up ....2 The 480i’s Options List ....3 Administrator Level Options ..3 Network: ........3 SIP Settings:......4 Phone Status: ......4 The Aastra 480i Web Client ..5 480i IP Phone Configuration ..6 Network........6 Turn DHCP On or Off ....6 Manually Configure Network Settings ....6 TFTP Server Settings....7...

  • Page 4: Overview

    This guide complements the new 480i phone. Aastra 480i Installation Guide and the • SIP standard "RFC 3261" Aastra SIP 480i IP Phone User Guide . • Access to a Trivial File Transfer • Aastra 480i Installation Guide – Protocol (TFTP) server.

  • Page 5: Methods Of Installation

    480i can be done through the or reset it will automatically Options List available directly from download any Þrmware updates the phone or through the Aastra 480i for the phone. The binary and Web Client web interface. When the conÞguration Þles that are required 480i is initialized for the Þrst time,...

  • Page 6: The 480I's Options List

    To assign your own DNS administrator is “22222”. For all addresses, disable DHCP. other phone options, please refer 6. TFTP Server to the Aastra 480i Installation Guide. This is the TFTP server’s IP The administrator level options in address. the phone’s Options List are: •...

  • Page 7: Sip Settings

    Note: For information on other settings in the options list of the phone, please refer to the Aastra 480i Installation Guide provided with the 480i. Model 480i SIP Admin Guide 4...

  • Page 8: The Aastra 480I Web Client

    The Aastra 480i Web Client To access the Aastra 480i Web Client, open your web browser (supports Internet Explorer and Gecko engine based browsers like Firefox, Mozilla or Netscape) and enter the phone’s IP address into the address Þeld, starting with the web preÞx “http://”.

  • Page 9: 480I Ip Phone Configuration

    480i through the 6. Press the softkey to £button on the phone or indicate whether DHCP should to start using the Aastra 480i Web be used or not. Client. See the section “The Aastra 7. Press to save the changes.

  • Page 10: Tftp Server Settings

    From the Web Client: SIP settings The 480i uses the information in 1. Click on the sub-category the SIP settings to register at the IP under the main category. PBX. To conÞgure the SIP settings: 2. Enter the administrator’s From the 480i Phone: user name and password (the default user name is “...
  • Page 11 "aastra.cfg" Þle conÞgures the settings server wide, while the <mac> conÞgures only the phones with the MAC address for which the Þle is named. The settings in the "aastra.cfg" Þle will be overriden by the settings which also appear in the <mac> cfg Þle.

  • Page 12: Setting Parameters Through Configuration Files

    The following section contains the parameters to conÞgure the network settings. Parameter – dhcp ConÞgurable through the 480i's Options List, the Aastra 480i web client or through the conÞguration Þles Description Enabling DHCP will populate most of the network information. The DHCP server should serve the network information that the 480i requires.
  • Page 13 Parameter – ConÞgurable through the 480i's Options List, default gateway the Aastra 480i web client or through the conÞguration Þles Description The IP address of the network's gateway or the router IP address Format IP address Default Value 1.0.0.1 Range...

  • Page 14: Setting Parameters - Time Server Settings

    Parameter – tftp server ConÞgurable through the 480i's Options List, the Aastra 480i web client or through the conÞguration Þles Description The TFTP server’s IP address. If DHCP is enabled and the DHCP server provides the information, this Þeld is automatically populated.
  • Page 15 Parameter – ConÞgurable through the 480i's Options List time server1 or the conÞguration Þles. Description The primary time server's IP address. If the time server is enabled, the value for time server1 will be used to request the time from. Format IP address Default Value...
  • Page 16 Parameter – ConÞgurable through the 480i's Options List time format or the conÞguration Þles Description This parameter changes the time to 12 hour or 24 hour format. Use “0” for the 12 hour format and “1” for the 24 hour format. Format Integer Default Value...

  • Page 17: Setting Parameters - Sip Authentication

    The following parameters are the settings speciÞc to SIP authentication. Parameter – sip proxy ip ConÞgurable through the 480i's Options List, the Aastra 480i web client or through the conÞguration Þles Description A SIP proxy is a server that makes and forwards requests generated by the 480i to the targeted user.
  • Page 18 Parameter – ConÞgurable through the 480i's Options sip registrar port List, the Aastra 480i web client or through the conÞguration Þles Description The registrar's port number Format Integer Default Value 5060 Range Not Applicable Example registrar port: 5060 Parameter –...
  • Page 19 Parameter – ConÞgurable through the conÞguration Þles. sip lineN auth name ConÞgurations done through the 480i's Options List or the Aastra 480i web client affect the Þrst line only. Description The authorization name that will be used in the username Þeld of the Authorization header Þeld of the SIP REGISTER request.
  • Page 20 Parameter – ConÞgurable through the conÞguration Þles. sip lineN user name ConÞgurations done through the 480i's Options List or the Aastra 480i web client affect the Þrst line only. Description The value for this parameter is used in the name Þeld of the SIP URI for the 480i phone and for registering the 480i at the registrar.

  • Page 21: Setting Parameters - Softkey Settings

    This section contains the softkey parameters that can be conÞgured on the 480i phone. There are eighteen softkeys that can be conÞgured. These parameters can be conÞgured either from the Aastra.cfg or the <mac>.cfg Þle. Softkeys can be conÞgured as either speed dials or as additional call/line appearances.
  • Page 22 Parameter – ConÞgurable through the conÞguration softkeyN value Þles only Description If the soft key is of type, line then value should be the line number that this soft key represents. If the softkey is of type, speeddial then value should be the number to speed dial.

  • Page 23: Firmware Upgrade

    3. In the Þeld, enter the Firmware Upgrade name of the Þrmware Þle that the The 480i phone uses a TFTP server phone should be upgraded with, to download conÞguration Þles and as shown in Figure 1. This name Þrmware. The TFTP server should must match the actual name of be ready and be able to accept the Þrmware Þle residing on your...
  • Page 24 Figure 1 Figure 2 21 Model 480i SIP Admin Guide...

  • Page 25: Troubleshooting

    IP Address displayed on 1. Click on the Reset sub-category the phone). Your browser will under the USER main category. launch the Aastra 480i IP Phone Firmware Recovery page. 2. On the web page that just opened click on button 3.
  • Page 26 How to set the 480i phone to factory default? From the 480i phone: 1. Press the £ button to enter the Options List. 2. Select option to enter the Phone Status options list. 3. Select option 4. Enter the administrator password and press the softkey.

  • Page 27: Appendix A: Configuring The 480I At The Asterisk Ip Pbx

    Appendix A: Configuring the 480i at the Asterisk IP PBX The following conÞguration illustrates how to create a user with an extension to make and receive calls using the Asterisk as the PBX. This conÞguration is deÞned in the “sip.conf” Þle present along with the other conÞguration Þles that are created when Asterisk is installed.
  • Page 28 After this is deÞned in the “sip.conf” Þle, some information has to be entered in the “extensions.conf” Þle present in the same directory as the “sip.conf” Þle. The following deÞnition in the Þle under the [sip]section/context completes deÞning the extension for the 480i phone. exten =>...

  • Page 29: Appendix B: Sample Configuration Files

    # from the TFTP server while restarting, the “aastra.cfg” Þle and # the “[mac].cfg” Þle. These two conÞguration Þles can be used to # conÞgure all of the settings of the Aastra 480i phone with the # exception of assigning a static IP address to a phone and line # settings, which can only be set in the “<mac>.cfg”...
  • Page 30 DHCP Setting ============ dhcp: 1 # DHCP enabled. # DHCP: 0 = false, means DHCP is disabled. 1 = true, means DHCP is enabled. # Notes: If DHCP is disabled, the following network settings will # have to be conÞgured manually either through the conÞguration # Þles, the Options List in the phone, or the Web Client: IP # Address (of the phone), Subnet Mask, Gateway, DNS, and TFTP # Server.
  • Page 31 SIP registrar and Proxy Server Settings ======================================= #sip proxy ip: # IP of proxy server. #sip proxy port: 5060 # 5060 is set by default. #sip registrar ip: # IP of registrar. #sip registrar port: 5060 # 5060 is set by default. sip digit time out: 4 # dialing behaviour #----------------------------------------------------------------------...
  • Page 32 # on the 480i phone. These can be set up through either of the 2 # conÞguration Þles, depending on whether this is to be server # wide (“aastra.cfg”) or phone speciÞc (“[mac].cfg”). # Each softkey needs to be numbered from 1 - 18, for example # “softkey12 type: speeddial”.
  • Page 33 softkey3 type: speeddial softkey3 label: “CallFwdOn” softkey3 value: *72 softkey4 type: speeddial softkey4 label: “CallFwdOff” softkey4 value: *73 softkey5 type: speeddial softkey5 label: “DND On” softkey5 value: *78 softkey6 type: speeddial softkey6 label: “DND Off” softkey6 value: *79 softkey7 type: speeddial softkey7 label: “CLIDBlock”...
  • Page 34 # dashes removed) of the speciÞc 480i device that you want to # conÞgure, for example “00085d03059f.cfg”. # Settings that have already appeared in “aastra.cfg” will be # overridden by those in this Þle. # Parameters can be set in either the “<mac>.cfg” Þle or the # “aastra.cfg”...
  • Page 35 Network Settings ================ #ip: # This value is unique to each phone on a server # and should be set in the “<mac>.cfg” Þle if # setting this manually. #---------------------------------------------------------------------- Line Settings ============= Lines should be set in the <mac>.cfg Þle since these settings are unique to each phone.
  • Page 36 # Explanation of Settings with Line 1 as Example # ============================================== #sip line1 auth name: # SIP Registrar request authorization name. #sip line1 password: # SIP Registrar request passcode. #sip line1 user name: # This parameter value is used by the 480i # in the From header Þeld of the outgoing # SIP packet.
  • Page 37 # on the 480i phone. These can be set up through either of the 2 # conÞguration Þles, depending on whether this is to be server # wide (“aastra.cfg”) or phone speciÞc (“[mac].cfg”). # Each softkey needs to be numbered from 1 - 18, for example # “softkey12 type: speeddial”.
  • Page 38 # Softkey Speed Dials # =================== For the default softkey speed dials, please refer to the sample “aastra.cfg” Þle. # Example Softkey Line/Call Appearances # ===================================== #softkey1 type: line #softkey1 label: “Line 5” #softkey1 value: 5 #softkey2 type: line #softkey2 label: “Line 6”...

  • Page 39: Appendix C: Tftp Server Set-Up

    Appendix C: TFTP Server Set-up There are a number of TFTP servers available. PumpKIN is one of such TFTP servers. Use the keywords “pumpkin TFTP server” on Google and you should get the web site where you can download the software from.

  • Page 40: Limited Warranty

    ßoods, after the telephone is authorized agents, or by others who in your possession. are legally authorized. This restriction Aastra Telecom shall not be liable for applies during and after the warranty period. Unauthorized repair will any incidental or consequential void the warranty.
  • Page 41 If you’ve read this owner’s manual and consulted the Troubleshooting section and still have problems, please visit our website at www.aastra.com or call 1-800-574-1611 for technical assistance. © Aastra Telecom Inc. 2005 41-0099-00 Rev 00...
