User's Manual
Fully Automatic Washing Machine
This manual is for
HWM75-7288
Please read this manual carefully before using.
Retain it for future reference.
Index
Safety precautions ............... 2
Packing list ........................... 4
Names of the parts ............... 4
adjustment............................ 5
washing ................................. 9
Use the operation buttons .... 11
Disposal after washing ......... 13
to question............................ 14
Spec cation ......................... 15
0030808632
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Haier HWM75-7288
Summary of Contents for Haier HWM75-7288
-
Page 1: Table Of Contents
......... 9 Use the operation buttons ..11 Disposal after washing ..13 Trouble-shooting Answer to question......14 Spec cation ......15 This manual is for HWM75-7288 Please read this manual carefully before using. 0030808632 Retain it for future reference. -
Page 2: Safety Precautions
Safety precautions Meaning and description of the symbols Contents marked with that symbol are related to the safety of the product and the personal safety of the users. Please operate in strict conformity to the contents, otherwise it may cause damage of the machine or injure the personal safety WARNING of the user. - Page 3 In case the washing machine is installed on ground with carpet, do not block the ventilation hole with carpet. Ensure carpet does not obstruct the opening in the bases. Do not put the machine at damp place like the bathroom. Never wash it with water. Do not put wet laundries on the control panel.
-
Page 4: Packing List
Packing list Fully automatic Water inlet hose Bottom plate Tapping screws User’s manual washing machine (One Piece) Warranty card Names of the parts Top lid Detergent box Control panel seat Outer tub cover Lint lter(2 pieces) Balance ring Inner tub Bleach inlet Hanging hole Filter cover(2 pieces) -
Page 5: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. After you open the package, please lean the washing machine gently down on soft Front items (like the towel cloth, blanket, ect. - Page 6 NOTE: The appliance is to be connected to the water mains using new hose-sets and that old hose-sets should not be reused. Confirm the water faucet It is required that the front end shall be longer than 10mm. The exit end face of the faucet shall be flat and smooth.If not please file it to avoid leakage. water faucet, not suitable water faucet, suitable The exit end face of the faucet...
-
Page 7: Connection Between The Water Inlet Hose And The Washer
Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before nut of the water each usage. If it happens please contact our inlet hose after-sale department immediately. -
Page 8: How To Change The Direction Of The Drain Hose
How to change the direction of the drain hose 1.D i smantle the back cover of the washing machine. 2.Press the spring lamination lightly and pull the top Back cover segment of the drain hose decumbent then put down the drain hose from the drain hose frame. D r ain hose frame 3.Put down the drain hose, squeeze the drain hose lightly and take off the hook, put the drain hose into... -
Page 9: Preparation Before Washing
Preparation before washing Connect the water inlet hose. Open the water faucet. Con rm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. The earth terminal shall not link to gas pipeline and faucet water pipeline. Put down the drain hose. - Page 10 The capacity of washing and spinning of he machine refer to the largest weight ofthe standard laundries under dry conditionthat can be washed or spinned in one time. One time washing quantity shall be lower than the rated capacity. The thickness, size, type of the cloth will in uence the actual washing capacity. It is suitable for one time washing to put in reasonable amount of laundries and the laundries can be turned round in washing.
-
Page 11: Use The Operation Buttons
Use the operation buttons Push the On/Off button to switch on the power. On: indicate the program about to run,or indicate When the power is on, push it again to the selected mode or indicate the water level switch off the power. Flashing: indicate the running program Push the On/Off button to switch on the power.If the start/pause button is... -
Page 12: Finish Washing
Push “ ” button to switch on the power Push “ ” button to select suitable automatic program After the power is switched on, “SOAK” is automatically set. To select other fully-auto program, please push the “PROGRAM” button till the corresponding indicator is on. Refer to the “Program”... -
Page 13: Disposal After Washing
Disposal after washing Please rst pull off the power plug from the receptacle before cleaning. After using, please clean the lint and foreign materials of the lint lter and over ow lter in time. Otherwise it may in uence your using the machine. Clean the detergent box and set it on the control panel seat. -
Page 14: Trouble-Shooting Answer To Question
Trouble-shooting Answer to question (If there’s breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please con rm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. -
Page 15: Spec Cation
Phenomena Explanation The spinning is intermittent when it starts. Balance the laundries to avoid slanting. Push the “spin” button to select “Spin”, but it doesn’t The program is setting the drain time. Some time is work. needed before it starts spinning. The nal spinning is nished, it becomes rinsing and Because the washing clothes lean to one side,the begins to inlet water.
