EPSON ActionNote 800 Series
External Keyboard/Mouse Connector (J7)
Microphone Connector (J8)
Pin
Signal
Pin
1
AGND
3
2
MICIN
4
Fax/Modem Connector (J15)
Speaker Connector (J18)
Pin
Signal
1
GND
FDD Connector (522)
AN800-6
Signal
Pin
Signal
BMIC
5
MICIN
BMIC
Pin
Signal
2
SPK
HDD IDE Connector (J23)
Pin No.
Signal Name
RESET DRV
1
2
GND
3
IDE D7
4
GND
5
SD8
6
SD6
7
SD9
8
SD5
9
SD10
10
SD4
11
SD11
12
SD3
13
SD12
14
SD2
15
SD13
16
SD1
17
SD14
18
SD0
19
SD15
20
GND
Memory Module Connector (J10)
12/9/94
Pin No.
Signal Name
21
GND
22
IOWR
23
GND
24
IORD
25
GND
26
IOCHRDY
27
IRQ14
28
IOCS16
29
SA1
30
GND
31
GND
32
SA0
33
SA2
34
HCS0
35
HCS1
36
HDDLED
37
VCC5
38
VCC5
39
GND
40
VCC5
