Specifications

Keyboards
• 88 Graded Hammer Standard keys (A-1–C7),
with Touch Response.
Display
• 320 x 240 dots LCD display (backlit)
Setup
• STANDBY/ON
• MASTER VOLUME: MIN–MAX
• LCD CONTRAST
Realtime Control
• Pitch Bend Wheel
Voice
• 142 panel voices + 12 drum/SFX kits + 381 XGlite voices
• Polyphony: 64
• DUAL
• SPLIT
Style
• 165 Preset Styles + External files
• Style Control: ACMP ON/OFF, SYNC STOP, SYNC
START, START/STOP, INTRO/ENDING/
rit., MAIN/AUTO FILL
• Fingering: Multi Finger, Full Keyboard, AI Fingered
• Style Volume
Music Database
• 305 + External files
Education Feature
• Dictionary
• Lesson 1–3, Repeat & Learn
Registration Memory
• 8 banks x 4 types
Function
• VOLUME: Style Volume, Song Volume
• OVERALL: Tuning, Transpose, Split Point, Touch Sen-
sitivity, Pitch Bend Range, Chord Fingering
• MAIN VOICE: Volume, Octave, Pan, Reverb Level, Cho-
rus Level, DSP Level
• DUAL VOICE: Volume, Octave, Pan, Reverb Level, Chorus
Level, DSP Level
• SPLIT VOICE: Volume, Octave, Pan, Reverb Level, Chorus
Level
• EFFECT: Reverb Type, Chorus Type, DSP ON/OFF,
DSP Type, Sustain, Master EQ Type
• HARMONY: Harmony Type, Harmony Volume
• Performance assistant technology:
Performance assistant technology Type
• PC: PC Mode
• MIDI: Local On/Off, External Clock, Initial Send,
Keyboard Out, Style Out, Song Out
• METRONOME: Time Signature Numerator, Time Signature
Denominator, Metronome Volume, Bell
• SCORE: Quantize
• SONG/LESSON: Lesson Track (R), Lesson Track (L)
• LESSON: GRADE
• DEMO: Demo Cancel, DEMO GROUP, DEMO
PLAY MODE
• LANGUAGE: English/Japanese
Effects
• Reverb: 35 types
• Chorus: 44 types
• DSP: 238 types
• Harmony: 26 types
Song
• 30 Preset Songs + 5 User Songs + Accessory CD-ROM
Songs (70)
• Song Clear, Track Clear
• Song Volume
• Song Control: REPEAT & LEARN, A-B REPEAT, PAUSE,
REW, FF, START/STOP
Performance assistant technology
• Chord, Chord/Free, Melody, Chord/Melody
Recording
• Song
User Song:
Recording Tracks: 1, 2, 3, 4, 5, STYLE
112
Owner's Manual
5 Songs
MIDI
• Local On/Off • Initial Send
• Keyboard Out • Style Out
Auxiliary jacks
• PHONES/OUTPUT, DC IN 12V, USB TO HOST, USB TO DE-
VICE, SUSTAIN, PEDAL UNIT
Amplifier
• 6W + 6W
Speakers
• 12cm x 2 + 3cm x 2
Power Supply
• Adaptor: Users within U.S or Europe: PA-150 or an equiv-
alent recommended by Yamaha
Others: PA-5D, PA-150 or an equivalent
Dimensions (W x D x H)
• 1,397 x 445 x 146 mm (55" x 17-1/2" x 5-3/4")
with keyboard stand:
1,399 x 445 x 761 mm (55-1/16" x 17-1/2" x 29-15/16")
Weight
• 20.7kg (45 lbs. 10 oz.)
with keyboard stand: 27.7kg (61 lbs. 1 oz.)
Supplied Accessories
• Data List
• Music Rest
• Accessory CD-ROM
• Keyboard Stand
• Owner's Manual
• Footswitch
• My Yamaha Product User Registration
* The PRODUCT ID on the sheet will be needed when you fill out
the User Registration form.
• AC Power adaptor (PA-150 or an equivalent)
* May not be included depending on your particular area.
Optional Accessories
• AC Power Adaptor:
Users within U.S or Europe: PA-150 or an equivalent
recommended by Yamaha
Others: PA-5D, PA-150 or an equivalent
• Headphones: HPE-150
• Pedal Unit: LP-7A
• Footswitch: FC4/5
* Specifications and descriptions in this owner's manual are for
information purposes only. Yamaha Corp. reserves the right to change
or modify products or specifications at any time without prior notice.
Since specifications, equipment or options may not be the same in
every locale, please check with your Yamaha dealer.
• External Clock
• Song Out
