Front Panel View

Status LED
A blinking light indicates
traffic is passing through.
Power LED
A solid green light
indicates the unit
is powered up.
DSL LED
A Solid light indicates the DSL
is synchronized. A flashing LED
indicates the modem is attempting to
synchronize with the DSL provider.
D-Link DSL-30B Quick Install Guide
Local Network LED
A solid light indicates a connection
to an Ethernet-enabled computer.
This LED blinks during
transmission.
Internet LED
A solid green light indicates
that the modem has an IP
address and is connected to
the internet.
USB LED
A Solid light indicates a connection is
established using USB. A flashing LED
indicates traffic is being sent and received
using USB.
