Lexmark J110 Appletalk Manual

Lexmark J110 Appletalk Manual

Appletalk and marknet print servers
Hide thumbs Also See for lexmark J110:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Reference Manual
Printing
Print materials
Supplies
Troubleshooting
Administration

Why you need to change the AppleTalk type

The J110 printer requires that you change the AppleTalk type in order for you to print
AppleTalk network print jobs.

Before you change the setting

Verify your printer hardware setup is complete. Refer to the printer setup guide for detailed
instructions.
Change the AppleTalk type
If you have TCP/IP available on your network, we recommend you assign an IP address to
the MarkNet print server. Running TCP/IP with your print server lets you use the full range of
print management tools and perform the easiest configuration.
Method 1 is an easy way to change the AppleTalk type for IP configured print servers. You
can use Method 2 as well.
If you are not running TCP/IP, you must use Method 2.
www.lexmark.com
AppleTalk and MarkNet print servers
Lexmark J110
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the lexmark J110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark lexmark J110

Summary of Contents for Lexmark lexmark J110

  • Page 1: Why You Need To Change The Appletalk Type

    Method 1 is an easy way to change the AppleTalk type for IP configured print servers. You can use Method 2 as well. If you are not running TCP/IP, you must use Method 2. www.lexmark.com Lexmark J110...
  • Page 2 Change Type to Hb PCL emulation. (The default is LaserWriter. LaserWriter will not work correctly with your J110 printer.) – Delete the Prefix and PostScript strings – Change Mode to RAW Click Submit to save your changes. www.lexmark.com Lexmark J110...

  • Page 3: Method 2 -- Universal Configuration Files (Ucf)

    Two universal configuration files (UCF) are shipped on the Drivers, MarkVision and Utilities Print materials CD. They are installed on your computer in a Lexmark Extras folder when you set up your printer. You can use MarkVision or ftp the files to the MarkNet print server.

  • Page 4: Set The Ip Address Using The Printer Operator Panel

    When you finish setting the IP address, press Select until the word SAVED appears briefly. Administration Set the IP netmask and gateway in a similar way. Print a network setup page to verify the parameters are set as you intended. www.lexmark.com Lexmark J110...

  • Page 5: Create A Desktop Printer

    Change the zone and printer name The MarkNet print server works automatically with AppleTalk networks. However, if you would like to use a zone and printer name different from the defaults, you can use MarkVision to change these settings. www.lexmark.com Lexmark J110...

  • Page 6: Install Markvision

    Insert the Drivers, MarkVision, and Utilities CD. Print materials Note: You may have more than one version of the Drivers, MarkVision and Utilities CD, received at different times with different Lexmark products. Always use the latest version CD. Supplies Select your language.

  • Page 7: Troubleshooting

    LocalTalk, you cannot see a printer on Ethernet unless there is a router on the network. If you still don’t see the printer in the Chooser, make sure AppleTalk is active on the workstation (look in the AppleTalk control panel). www.lexmark.com Lexmark J110...

  • Page 8: Light Patterns On The External Print Server

    AppleTalk and MarkNet print servers Printing If you are still having trouble with the hardware, contact Lexmark for help. See “Lexmark customer support” on page 13. Print materials Light patterns on the external print server MarkNet external print servers indicate activity, status, and errors by various cyclical patterns on the four indicator lights.
  • Page 9 AppleTalk and MarkNet print servers Printing Print materials Pattern binary binary binary Supplies binary binary binary Troubleshooting binary binary binary binary Administration binary Four indicator lights binary binary binary binary binary www.lexmark.com Lexmark J110...

  • Page 10: Error Conditions

    (for 0.25 sec), server. repeat continuously. 1 Reset the print server. where x could be 0, 1, Administration 2 If the problem reoccurs, call Customer 2, 3, 4, 5, 6, 7, 8, or 9 Support. www.lexmark.com Lexmark J110...
  • Page 11 Supplies server. This is to make sure you see that a parity error occurred. To turn parity checking off, use a utility or telnet to port 9000.) Troubleshooting 2 Send the job again. Administration www.lexmark.com Lexmark J110...
  • Page 12 The printer was turned off while the serial job The two parallel ports was printing. are unaffected. Troubleshooting 1 Turn the printer back on. The print server then flushes the current job. 2 Send the job again. Administration www.lexmark.com Lexmark J110...

  • Page 13: Lexmark Customer Support

    Print materials CompuServe Go Lexmark Internet ftp.lexmark.com Supplies U.S. and Canada, technical support 1-800-LEXMARK and any other customer needs Troubleshooting Lexmark phone numbers On the Drivers, MarkVision and Utilities CD, click (worldwide) Contact Lexmark, Customer Support. Administration www.lexmark.com Lexmark J110...
