Dual Speed Switch 8 and Dual Speed 16—Front
Alert LED
orange
Off when the unit is operating correctly.
Flashes for a short period of time after
power on, for self test.
If the LED is continuously lit, there may
be a problem. Refer to the "Problem
Solving" section.
Link : On=OK, Flash=Activity
Duplex : On=Full
Speed : On=100M
Alert Power
Link/Activity, Duplex and Speed LEDs
Power LED
green If the Link/Activity LED
equipment is OK. The LED flashes each time a packet passes through the port.
Indicates that
If the LED is off, the port does not have anything connected to it, or the connected device is
the power
switched off. If you have made a connection to the port and the LED is off, there may be a problem
supply to the
with the connection (refer to the "Problem Solving" section).
switch is
present. If the Duplex LED
If the Speed LED
10/100 Base - TX
1 3 4 5 7 8
2 6
is on (green), the link between the port and the next piece of network
is on (yellow), the port is in full duplex mode. If off, it's half duplex.
is on (green), the port is operating at 100Mbps. If off, it's 10Mbps.
10/100 Base - TX
9 10 11 13 14 15
12 16
OfficeConnect Dual Speed Switch 16
7
