- Page 1 3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough, MA 01752-3064 www.3Com.com 10016681 REV BA June 2008 User Guide OfficeConnect Gigabit Switch 5 (3C1670500C) Gigabit Switch 8 (3C1670800C) ®...
-
Page 2: Dimensions And Standards
This switch is one of the most compact designs in the industry making it ideal for desktop use, and in keeping with the 3Com GreenConnect* tradition, this switch incorporates the latest 65nm technology. This allows for lower power con- sumption and decrease in carbon footprint. It can be used... - Page 3 GREENCONNECT Your OfficeConnect Gigabit Switch employs a number of initiatives to ensure your product uses the least amount of power possible: 1. High Efficiency Power Adapter The Power Adapter is a model especially designed to meet the Energy Star requirements for operating efficiency and ™...
- Page 4 ABOUT YOUR SWITCH OfficeConnect Gigabit Switch - Front Green = 1000M, Yellow = 10/100M, Flash = Activity 1 Power LED (Illuminated Logo) Green Indicates that the Switch is receiving power. If the LED is off there may be a problem with the power adapter, power adapter cable or the Switch's internal power supply.
-
Page 5: Positioning Your Switch
• Water or moisture cannot enter the case of the unit. • Air flow around the unit and through the vents in the side of the case is not restricted. 3Com recommends you provide a minimum of 25 mm (1 in.) clearance. -
Page 6: Wall Mounting
Wall Mounting There are two slots on the underside of the Switch that can be used for wall mounting. The Switch must be mounted with the LEDs facing upwards. When wall mounting the unit, ensure it is within reach of the power outlet When wall mounting the unit, ensure that the rubber feet are not fixed Mounting Instructions for Cement Walls... -
Page 7: Connecting Workstations
3 CONNECTING WORKSTATIONS Twisted Pair (TP) Cables Cables can be shielded (screened) or unshielded. Cables must be Category 5 or above. 3Com recommends Category 5E cable for Gigabit connections. The maximum length you can use is 100 m (328 ft). - Page 8 The Switch has automatic MDI/MDIX functionality. Simply plug in the cable, and the Switch will automatically detect which wiring practice has been followed, and will compen- sate accordingly. Checking Unit Connections When you have connected all your units, power on the units and the Switch.
-
Page 9: Problem Solving
The power adapter or power adapter connection is likely to be faulty. Check your power adapter connection. If there is still no power, contact 3Com Technical Support and ask for a replacement power adapter. Please quote the power adapter part number, shown on the OfficeConnect power adapter you are currently using or refer to the table on next page. -
Page 10: Important Safety Information
Support and Safety Information Important Safety Information WARNING: Warnings contain directions you must follow for your personal safety. Follow all directions carefully. You must read the following safety information before carrying out any installation or removal of the unit, or any maintenance procedures. WARNING: Exceptional care must be taken during installation and removal of the unit. -
Page 11: Wichtige Sicherheitsinformationen
Consignes de sécurité importantes Avertissement: Ces avertissements sont à respecter pour votre sécurité. Lisez-les attentivement. Vous devez impérativement lire les consignes de sécurité suivantes avant de procéder à l’installation ou à la désinstallation du matériel, ou à toute activité d’entretien. Avertissement: L’installation et la désinstallation du matériel nécessite une vigilance exceptionnelle. -
Page 12: Importanti Informazioni Di Sicurezza
Importanti informazioni di sicurezza Avvertenza: Queste avvertenze precisano le direttive da seguire per la propria sicurezza personale. Conformarsi con la massima attenzione a quanto precisato. Leggere con attenzione le informazioni relative alla sicurezza prima di procedere all’installazione o alla rimozione dell’unità o a qualsiasi intervento di manutenzione. -
Page 13: Environmental Statements
Do tych gniazd moż na podł ączać kable danych ekranowane lub nieekranowane z ekranowanymi lub nieekranowanymi wtykami. ENVIRONMENTAL STATEMENTS For further details please refer to http://www.3com.com/environment/index.html REGULATORY NOTICES FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 14 Manufacturers Declaration of Conformity 3Com Corporation, 350 Campus Drive, Marlborough, MA 01752-3064, USA Declares that the following products: Date: June 2008 Brand Name: 3Com Corporation Model Nos.: 3C1670500C, 3C1670800C Equip Type: Gigabit Switch 5 / Gigabit Switch 8 Complies with Part 15 of the FCC rules. Operation is subject...
- Page 15 • A list of system hardware and software, including revision level • Diagnostic error messages • Details about recent configuration changes, if applicable To send a product directly to 3Com for repair, you must first obtain a return materials authorization number (RMA).
- Page 16 RMA num- ber online at http://eSupport.3com.com/. First-time users must apply for a user name and password. Telephone numbers are correct at the time of publication. Find a current directory of 3Com resources by region at: http://csoweb4.3com.com/contactus/ Country Telephone Number Asia, Pacific Rim —...
