Dual Speed Switch 4—Front
Alert LED Power LED
orange green
Same as Switch 8 and Indicates that the
Switch 16. power supply to the
switch is present.
Link : On=OK, Flash=Activity
Duplex : On=Full
Speed : On=100M
Alert Power
N
ETWORK
Port Status and Activity LEDs
If the Port Status LED
and the next piece of network equipment is OK. If the LED is
off, nothing is connected, or the connected device is switched
off, or there is a problem with the connection (refer to the
"Problem Solving" section).
The Activity LED
through the port.
10/100 Base - TX
1 2 3 4
is on (green), the link between the port
flashes (yellow) each time a packet passes
OfficeConnect
6
Speed 100 and Full Duplex LEDs
If the Speed 100 LED
port is operating at 100Mbps. If the LED
is off, the port is operating at 10Mbps.
If the Full Duplex LED
port is in full duplex mode. If the LED is
off, the port is in half duplex mode.
Dual Speed Switch 4
