NEW FEATURES OF VERSION 2
EN
The following new features have been added with version 2.
• Previews of embroidery patterns can be magnified by 200%.
• Thumbnails of embroidery patterns can be displayed at a larger size.
• An image of the needle position being displayed by the built-in camera or an image of the Settings screen can be saved in the
BMP format on USB media.
• A grid can be displayed to check the needle position in the LCD. This enables easy alignment of the needle position.
• Various improvements in operation and screen displays have been incorporated, making the machine easier to use.
For details, refer to the following descriptions.
DISPLAYING PATTERNS IN THE
EMBROIDERY EDIT SCREEN
MAGNIFIED BY 200%
In the Embroidery Edit screen, the pattern can be
magnified by 200% within the embroidery display area.
a
Press .
→
changes to
magnified by 200%.
b
Check the displayed pattern.
→
Use
display in any direction.
c
To display the pattern back to the normal
size (100%), press
, and the pattern is
to scroll through the
.
SPECIFYING THE SIZE OF
PATTERN THUMBNAILS
The thumbnails for selecting an embroidery pattern can
be set to be displayed at the normal size or a larger size.
The larger size is 1.5 times the normal size.
The thumbnail size setting can be selected from page 8/8
of the Settings screen.
a
Press or to select the desired
thumbnail size.
Note
• When thumbnail size setting has been changed the
pattern selection screen will not immediately reflect the
chosen size. To view the patterns with the new thumbnail
size, return to the category selection screen, and then
select the pattern category again.
