Chapter 2 Switch Installation

Mounting the Switch on a Wall

For the best support of the switch and cables, make sure the switch is attached securely to wall studs or
to a firmly attached plywood mounting backboard. Mount the switch with the front panel facing up, as
shown in
Warning To comply with safety regulations, mount switches on a wall with the front panel facing up.
Statement 266
Figure 2-18
1
After the switch is mounted on the wall, you need to do these tasks to complete the installation:
•
•
•
For configuration instructions about using the CLI setup program, go to
Switch with the CLI-Based Setup Program."
OL-7678-01
Figure 2-18.
Mounting the Switch on a Wall
1
User-supplied screws
Power on the switch. See the
Connect to a 10/100 port, and run the Initial Configuration Dialog. See the Cisco ME 3400 and ME
2400 Ethernet Access Switches Getting Started Guide for instructions.
Connect to the front-panel ports. See the
the "Connecting to SFP Modules" section on page 2-23
"Verifying Switch Operation" section on page
"Connecting to the 10/100 Ports" section on page 2-22
Cisco ME 2400 Ethernet Access Switch Hardware Installation Guide
Installing the Switch
1
2-7.
to complete the installation.
Appendix D, "Configuring the
and
2-17
