Toshiba 39L4300UM User Manual

Integrated high definition led television.
Hide thumbs

Advertisement

Integrated High Definition LED
Television User's Guide:
32L4300U / 39L4300U / 50L4300U
50L7300U / 58L7300U / 65L7300U
If you need assistance:
Toshiba's Support Web site
For more information, see
Owner's Record
The model number and serial number are on the back and side of your television.
Record these numbers, whenever you communicate with your Toshiba dealer about
this Television.
Model name:
Serial number:
Register your Toshiba Television at register.toshiba.com
Note: To display a High Definition
picture, the TV must be receiving a
High Definition signal (such as an over-
the-air High Definition TV broadcast, a
High Definition digital cable program,
or a High Definition digital satellite
program). For details, contact your TV
antenna installer, cable provider, or
satellite provider
support.toshiba.com
"Troubleshooting" on page 160
in this guide.
GMA300019010
3/13
