Supported Devices

Software Version 1.1, under Windows NT 3.51, 4.0, supports the devices listed in Table 4 at the
indicated hardware and Microcode levels or higher.
Table 4 Supported Disk Drives
Part Number
DS–RZ1CF–VW
DS–RZ1DF–VW
DS–RZ1EF–VW
DS–RZ1CD–VW
DS–RZ1DD–VW
DS–RZ1ED–VW
DS–RZ1BB–VW
DS–RZ1CB–VW
DS–RZ1DB–VW
DS–RZ1DA–VW
DS–RZ1EA–VW
DS–RZ1FB–VW

On-line Documentation

Your RAID Array 3000 reference manuals are part of the RAID Array 3000 V1.2 for Windows
NT –Alpha CD-ROM. They can be viewed and printed using Adobe Acrobat Reader when
installed on an Alpha-based Windows platform. A copy of the reader is included in the CD-ROM
for your convenience.

RAID Array 3000 Operating Constraints

Controller
Always Operate Your RAID Array 3000 with the UPS-to-Pedestal Serial Cable Connected
The UPS serial cable must be connected at all times. This cable is used to communicate a power
failure to the controller. When the controller senses a power failure, it automatically saves your
data to disk. The purpose of the UPS is to keep your system running until the controller
accomplishes its task of saving cache data to disk.
Wait Until the Disk Drive Fault Indicator Clears Before Using the Disk
Disk Drive fault LED clearing takes approximately two minutes. Do not attempt to use a disk drive
until its fault indicator turn off.
AA–RACVC–TE
Description
4.3GB, 7200RPM disk in 3.5" SBB
9.1GB, 7200RPM disk in 3.5" SBB
18.2GB, 7200RPM disk in 3.5" SBB
4.3GB, 10000RPM disk in 3.5" SBB
9.1GB, 10000RPM disk in 3.5" SBB
18.3GB, 10000RPM disk in 3.5" SBB
4.3GB, 7200RPM disk in 3.5" SBB
9.1GB, 7200RPM disk in 3.5" SBB
9.2GB, 7200RPM disk in 3.5" SBB
9.1GB, 7200RPM disk in 3.5" SBB
18.2GB, 7200RPM disk in 3.5" SBB
36.4GB, 7200RPM disk in 3.5" SBB
Minimum Firmware Level
0371/N1H1/1614
0371/N1H1/1614
0371/N1H1
0306
0306
0306
LYJ0/0658
LYJ0/0658
LYJ0/0658
3B05
3B05
3B05
