Allied Telesis AT-8POE Datasheet

Datasheet | Switches
AT -8000/8POE
8 port 10/100TX Layer 2 Managed PoE Switch
AT -8000/8POE
8 port 10/100TX Layer 2 managed PoE switch
with 1 copper Gigabit port and 1 combo SFP
slot
High Performance
Allied Telesis managed switch AT-8000/8POE
provides non-blocking, wirespeed switching on
all ports.The switch offers 10/100Mbps ports for
desktop, wireless access point, printer and IP
phone connectivity and 10/100/1000T or SFP
ports for server or backbone connectivity. It also
features broadcast-storm control and full auto-
negotiation 10/100 ports which automatically
detect speed and duplex modes of attached
devices, allowing the switch to automatically
configure for the best possible performance.
Easy To Use
Allied Telesis AT-8000/8POE is tailored for
small and medium size networks including
hotels, schools and universities. Allied Telesis
AT-8000/8POE switch supports Power over
Ethernet (PoE) which reduces the cost and
complexity of IP communications and wireless
LAN deployments. PoE is an advanced
technology that allows a switch to supply
power and provide Ethernet connectivity at the
same time over category 5 cable to inline
power devices, such as wireless access points,
cameras, IP phones.The PoE ports eliminate the
cost and complexity of running additional
power outlets or cable to inline power devices.
Allied Telesis
Management
Although a plug & play device, the
AT-8000/8POE switch includes an extensive
range of management features including
Web-based management, Command Line
Interfaces (CLI), SNMP and Telnet.
The AT-8000/8POE switch can be used as a
desktop switch or in a rack.The switch is
MDI/MDI-X on all ports for simple connection
to other hubs and switches. Front panel LEDs
allow users to monitor the switch status providing
simple 'at a glance' management.
Rich Feature Set
Richly equipped with features normally found
on higher-priced products the AT-8000/8POE
switch supports RADIUS,VLAN tagging and
more. Bandwidth hungry networks can
streamline traffic with the four priority queues
found in the IEEE 802.1p prioritization feature.
High traffic points can be addressed with the
IEEE 802.1ad link aggregation and LACP feature
supported. Built-in advanced security features,
including security with IEEE 802.1x
authentication help ensure that your devices and
network are protected.
Key Features
• SNMP v1 and v2
• Telnet remote login
• Non blocking architecture
• Wirespeed performance
• Rapid Spanning-Tree
• RADIUS
• Four priority queues per port
• VLAN tagging
• Port mirroring
• Link aggregation - LACP*
• SNTP*
• GVRP*
• IEEE 802.3af Power over Ethernet
* future release
