HP NetServer LH 3000/3000r
A
Cabinet
Caution: DO NOT operate server for more than
60 minutes with any cover (including Power
Supply and Disk Drive) removed. Over-
temperature may cause component damage.
Primary
Processor
Secondary
Processor Slot
(Terminator in Place)
Non-Hot-Swap
Shelves:
Shelf 1:
Flexible Disk Drive
Shelf 2:
CD-ROM
Shelves 3 & 4:
Optional Mass
Storage Devices
Hot-Swap Mass Storage:
Secondary Cage
(Optional)
Primary Slots (1- 6 )
B
Primary Processor
Secondary Processor
Slot (Upgrade)
Temperature
Sensors:
Primary (U18)
(Under Processor)
Secondary (U17)
Terminator
0
1
DIMM Memory
Sockets
2
3
System Board Assembly
See
Board Stiffener
System Board
I/O Connectors
Processor Fan
Processor Cage
Cover
DIMM Slots
Exhaust Fans
Air Baffles
Front Panel Console
Lock
Power
and Indicator
Select
Back
Pair A
Power
Supply
Pair B
Fans:
Primary Voltage Regulator
Boot Order
Default Boot Order
Module (VRM)
1.
IDE CD-ROM Drive
Secondary VRM
2.
Flexible Disk Drive
Slot
3.
Embedded SCSI
4.
Other SCSI Device
(Settable)
CMOS Battery
Configuration
Switches
Serial
Parallel
Mouse
Keyboard
LAN
Video
:
B
Reset (located under cover)
Keyboard Lock
and Indicator
Reset
Server Status
LEDs
2-Line Display
Scr
Not Used
oll 2-Line Display
Quick Reference
C
LED Interpretation
Off = No Power, or Normal
Green Solid = Normal, or Power On
Green Flashing = Normal Activity
Only Green Flashing (RJ-45) = 10 Mbps
Amber (HDD) = Failure Predicted
Yellow Flashing = Pre Failure Condition
Amber (PCI Slot) = Slot Needs Attention
Yellow (RJ-45) = LAN is 100 Mbps
Red Solid = 12 V Failure
Red Flashing = Failure, Immediate Attention
Audience Assumptions
I/O Connectors
This Technical Reference Card is for trained
service personnel. Hewlett-Packard Company
assumes you are qualified in the servicing of
computer equipment and trained in recognizing
hazards in products with hazardous energy
levels.
This information is subject to change without
notice and is provided without warranty.
D8228-80201, Rev A
BARCODE AREA
I/O Connectors
B
See
PCI Slots:
1
2
3
4
5
6
7
8
4
Unused
3
Optional Redundant
2
Power Supply Slot
1
Power Supply Connector
and Strain-Relief
Power Supplies
Note: See HP NetServer LH 3000/3000r
Installation Guide
DIMM Installation
Use up to 4 HP SDRAM DIMMs in sizes
of 128MB, 256MB, 512MB, and 1GB.
First DIMM is supplied in Slot 0.
You can add DIMMs to Slots 1, 2, or 3
in any order.
Maximum system size is 4GB.
You can insert any approved size DIMM
in any DIMM slot.
Electrostatic Discharge
To avoid catastrophic or hidden damage to
components, wear a wrist strap and use a static-
dissipative work surface connected to the chassis
when handling components. Use an antistatic
service kit, such as 3M
8501/8502/8505 or
®
equivalent.
© Copyright 1999 Hewlett-Packard Company
For additional information, see other side.
